Compact 1 trunking
Boxes and plates
*RCD/MCB housing
code
pack
EAHC1MWH
1
*Up to 4 modules can be
accommodated
Note:
RCDs are not supplied by
Marshall-Tufflex
Main crossover bridge
code
pack
EMCB1
5
Provides segregation of services
crossing from one compartment
to another
Angled cable retainer
code
pack
EACR1
10
Provides cable retention in the
upper angled or square
compartment.
Main cable retainer
code
pack
EMCR1
10
The recommended cable
retainer for all compartments
which use the ETL1WH lid.
Angled mini-trunking
adapter
code
size
pack
EATA2WH
MMT2
5
Allows the transfer of cables
from Compact 1 to Marshall-
Tufflex Mini-Trunking
Angled mini-trunking
adapter
code
size
pack
EATA4WH
MMT4
5
Allows the transfer of cables
from Compact 1 to Marshall-
Tufflex Mini-Trunking
1 gang accessory box
code
depth pack
ESSB1WH
30mm 20
2 gang accessory box
code
depth pack
ESSB2WH
30mm 10
1 gang adjustable
depth box
code
depth pack
EAB1WH
32 – 40mm 10
EAB1 is fully adjustable to
47mm. Please see page 311
for more information.
2 gang adjustable
depth box
code
size
pack
EAB2WH
32 – 40mm 5
EAB2 is fully adjustable to
47mm. Please see page 311
for more information.
1 gang accessory
plate
code
pack
ESSP1WH
10
2 gang accessory
plate
code
pack
ESSP2WH
5
Dividing fllet
code
pack
EDF1
8 x 3m
Bonding strap
code
pack
ESBS1
5
Steel screening divider
code
pack
ESF1
1
Note:
optional steel screening
divider to assist in compliance
with BS EN 50174-2
p270
Technical
Information
Steel screening divider
bonding strap
code
pack
ESF2
5
Fittings
Part M
For boxes that meet
the requirements of
Part M (DDA) please
refer to page 106.
