Sterling Profle 1
trunking assembly
code
size
pack
EP1MWH 167 x 50mm 1 x 3m
Tel
+44 (0)1424 856600
Fax
+44 (0)1424 856611
Technical Hotline
+44 (0)1424 856688
PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
124 |
Sterling Profile 1, 2 and 3
Product information
•
167 x 50mm
•
3 segregated compartments
•
Outer compartments can be subdivided
•
Suitable for dado and skirting application
•
Can be fed from larger trunking systems for increased cable distribution
•
Boxes available to comply with Part M (DDA)
•
Comprehensive range of flush power and data accessories
•
Improved design to base unit to give greater cable capacity
•
Moulded fttings with Profle 1 and Profle 2
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 50mm
•
Compartment can be screened against EMI with no reduction (refer to p103)
in cable capacity
•
Adjustable data box 32-40mm
•
Screened data boxes
•
Steel screening divider available
Three segregated
compartments
Separate cover access
to each compartment
Part M
For boxes that meet the
requirements of Part M
(DDA) please refer to
page 106 of this section.
Colour options:
Charcoal solid
colour option is available as
standard item for selected fittings.
Please indicate when ordering
by replacing the WH colour code
suffix with CH for charcoal.
Sterling Profle 2
size
167 x 50mm
Trunking profiles
Basic components
Sterling Profle 3
size
167 x 50mm
Main compartment cover
code
pack
ETL1WH
8 x 3m
Angled cover
code
pack
ETAC1WH
8 x 3m
Square cover
code
pack
ETSC1WH
8 x 3m
Base unit
code
pack
ETB1M
4 x 3m
Sterling Profile systems 1 to 3 are popular and stylish looking
perimeter dado and skirting systems that are easy and cost
effective to use. A firm favourite for many years due to its
versatility, range of fittings and accessories and suitability for
many different cable management installation needs.
All above covers are also available from stock in charcoal.
WH
CH
Standard Colours
WH
: White
CH
: Charcoal
antimicrobial trunking
PAGE
107
‘Biooption’available
tospecialorder
Trunking Assemblies
Sterling Profle 1 is available
to order as a trunking
assembly using code
EP1MWH. Other profles
should be ordered using
the relevant base unit and
cover codes to make up the
assembly.
NEW
See
page 128
for quick
reference
chart
