PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
130 |
Sterling Curve
Curve Profle 1
trunking assembly
code
size
pack
CEP1MWH
167 x 50mm 1 x 3m
PAGE
107
Sterling Curve Profile 1 and 2 are stylish curved perimeter
dado and skirting systems that are easy and cost effective
to use. A new addition to the popular and proven Sterling
trunking system, Sterling Curve is a sleek data compliant
medium sized trunking system with three segregated
compartments. The adaptable system has 1 or 2 curved
data compartments designed to stop clutter, avoid dust
traps and to make cleaning easy.
Product information
•
167 x 50mm
•
3 segregated compartments
•
Suitable for dado and skirting application
•
Boxes available to comply with Part M (DDA)
•
Comprehensive range of flush power and data accessories
•
Single piece moulded fttings
•
Flat Tees and Flat Angles have integral bend radius control
•
Profle 1 is available in charcoal as standard
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 50mm
•
Compartment can be screened against EMI with
no reduction in cable capacity (refer to p103)
•
Adjustable data box 32-40mm
•
Screened data boxes
•
Steel screening divider available
Trunking profiles
Basic components
p278
Technical
Information
Curve Profle 2
size
167 x 50mm
antimicrobial trunking
WH
CH
Standard Colours
WH
: White
CH
: Charcoal
Colour options:
Charcoal solid
colour option is available as
standard for selected fittings.
Please indicate when ordering by
replacing the WH colour code suffix
with CH for charcoal.
Main compartment cover
code
pack
ETL1WH
8 x 3m
Curve cover
code
pack
CETC1WH
8 x 3m
Square cover
code
pack
ETSC1WH
8 x 3m
Base unit
code
pack
ETB1M
4 x 3m
Above covers also available in charcoal
Trunking Assemblies
Sterling Curve Profle 1
is available to order as a
trunking assembly using
code CEP1MWH. Other
profles should be ordered
using the relevant base unit
and cover codes to make up
the assembly.
NEW
See
page 135
for quick
reference
chart
