PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
136 |
Sterling Profile 4 to 13
Base extension
code
pack
EBE1WH
4 x 3m
Extendable base
code
pack
EEB1
4 x 3m
Base unit
code
pack
ETB1M
4 x 3m
Trunking profiles
Basic components
Sterling Profile systems 4 to 13 are perimeter dado and
skirting trunking systems that provide increased cable
capacity with large multi compartments that can be
subdivided to carry a greater range of services.
Product information
•
Profle 4 and 5 = 218 x 50mm
•
Profle 11, 12 and 13 = 255 x 50mm
•
Profle 6 = 269 x 50mm
•
3 and 4 large, segregated compartments
•
Can be subdivided
•
Suitable for dado and skirting application
•
Can be fed from larger trunking systems for
increased cable distribution
•
Boxes available to comply with Part M (DDA)
•
Comprehensive range of flush power and data accessories
•
Improved design to base unit to give greater cable capacity
and with side wall knockouts
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 50mm
•
Adjustable data box 32-40mm
•
Screened data boxes
•
Steel screening divider available
Three and four larger
compartments for
extra cable capacity
Separate covers for
each compartment
Can be subdivided
Sterling Profle 4
size
218 x 50mm
Sterling Profle 5
size
218 x 50mm
Sterling Profle 6
size
269 x 50mm
Sterling Profle 11
size
255 x 50mm
Sterling Profle 12
size
255 x 50mm
Sterling Profle 13
size
255 x 50mm
Part M
For boxes that meet the
requirements of Part M
(DDA) please refer to
page 106 of this section.
Standard colour
WH
WH
: White
PAGE
107
antimicrobial trunking
‘Biooption’available
tospecialorder
See
page 142
for quick
reference
chart
