PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
Mono Plus 30 trunking | 115
Basic components
Fittings
Trunking
(including 2 segregators)
code pack
EMT30WH 4 x 3m
Main compartment cover
code pack
ETL1WH 8 x 3m
External bend
code pack
EXB30WH 5
Internal bend
code pack
EIB30WH 5
End cap
code pack
EEC30LHWH (left hand) 5
EEC30RHWH (right hand) 5
Coupler
code pack
EC30WH 5
Flat angle – upward
code pack
EFA30UWH 1
Fabricated
Flat angle – downward
code pack
EFA30DWH 1
Fabricated
Mono Plus 30 is an economical and stylish
three-compartment compact skirting system,
particularly suitable for general
office applications.
Product information
• 155 x 55mm
• 1 main compartment and 2 smaller outer
• compartments
• Can be subdivided
• Suitable for skirting or worktop application
Data information
• Standard bend radius 25mm
• Data fttings available for bend radius up to 50mm
• Adjustable data box 32-40mm
• Screened divider and data boxes
Three segregated
compartments
Dividing fllet option for
centre compartment
Smallest 3
compartment
skirting trunking
option that accepts
standard power,
voice and data
accessories
Single Cover
Part M
For box assemblies that
meet the requirements
of Part M (DDA) please
refer to page 106.
Standard colour
WH
WH: White
p272
Technical
Information
PAGE
107
