PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
Steel screening divider
bonding clip
code
pack
ESF3
5
110 |
Odyssey
Screening
Conductive spray (CS) is unique to
Marshall-Tufflex and is applied in
the factory to provide screening
from electromagnetic interference
to data and communications cabling
with trunking systems. The coating is
applied to a range of data boxes,
covers, clip-on components and
fabricated fttings.
WARNING
: A CS coating is not suitable for low voltage circuits.
BS7671:2008. For data/voice use only
.
DD1001
DD1002
DD1412
DD1432
DD1511
DD1521
Odyssey trunking assembly
screened – 1 compartment only
Pack
1 x 3m
Odyssey trunking assembly
screened – compartment 1 & 3
Pack
1 x 3m
Flat angle (1 & 3)
Pack
1
Flat tee (1 & 3)
Pack
1
For covers only, please contact
the technical team
1 gang accessory box
Pack
1
2 gang accessory box
Pack
1
3 Compartment
Odyssey CS1
Odyssey screened
component chart
Bonding strap
code
pack
DD1711
5
Steel screening divider
code
pack
DD1730
1
Note:
optional steel screening
divider to assist in compliance
with BS EN 50174-2
Odyssey can enhance the look of a project as well as providing
all of the practical features that ensure fast and easy installation.
Odyssey Trunking
No mitreing/cutting of
corners required.
Recessed boxes for
curved accessories
Flush accessories to
maintain a smooth profile.
Pre-punched bases
Elongated holes at
200mm intervals
for quick installation.
Built-in cable tray
Allows cable support
during installation.
Acts as reinforcement
for outer covers
improving mechanical
and impact resistance.
3-part tee
Full cable segregation
and data compliance.
No couplers required.
Striking curved profile
Dust traps avoided,
clutter can’t be gathered
and cleaning easier.
Fixed & adjustable
internal & external bends
Accommodates building
intolerances in corners
with +/- 5° exibility.
