PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
108 |
Odyssey
Three
segregated
compartments
Internally
reinforced
for extra
mechanical
strength
Trunking assembly
(base and 3 covers)
code
size
pack
DD1WH
180 x 57mm 1 x 3m
Coupler
code
pack
DD1210WH
1
End cap
code
pack
DD1230WH
2
Internal bend
code
pack
DD1310WH
1
Flat angle up/down
code
pack
DD1410WH
1
Flat tee 3 part assembly –
up/down
code
pack
DD1430WH
1
Internal bend adjustable
code
adjustable pack
DD1330WH
85–95°
1
External bend
code
pack
DD1350WH
1
External bend adjustable
code
adjustable pack
DD1370WH
85 – 95°
1
Trunking profile
Fittings
Odyssey is a three-compartment trunking
system with a completely curved front profile
designed with tamper-resistant covers and
fittings and flush accessories to enhance the
finished appearance. Odyssey’s curved profile
is easy to clean and prohibits surface clutter.
Product information
•
180 x 57mm
•
1 main compartment and 2 smaller outer compartments
•
Can be subdivided
•
Suitable for dado application
•
Available in antimicrobial Bio option (see page 109)
•
Flush ftting accessories
•
Tamper resistant covers and fttings
Data information
•
Standard bend radius 25mm
•
Data fttings available for bend radius up to 65mm
•
Steel divider available to BS EN 50174-2
•
Can be screened against EMI with no reduction in cable capacity
•
Adjustable data box 32-40mm
•
Screened divider and data boxes
Flush ftting accessories
Tamper resistant
fttings that locate
with a special
clip design
antimicrobial trunking
PAGE
107
Curved profle does not allow
placement of objects
Flat tee cover
An option is available to order a flat tee cover only.
Please call the Technical Team on +44 (0)1424 856688.
Part M
The Odyssey trunking range
includes unique coloured
accessory boxes that meet the
requirements of Part M (DDA)
please refer to page 106.
Standard colour
WH
WH
: White
