PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
www.marshall-tufflex.comOdyssey
| 109
Fittings
Boxes
Bio
*RCD housing
code
pack
DD1580MWH
1
*Up to 4 modules can be
accommodated
Note:
RCDs are not supplied
by Marshall-Tufflex
DD1540 is fully adjustable to
47mm. Please see page 311 for
more information.
*1 gang
adjustable depth box
code
depth pack
*DD1540WH
32 – 40mm 10
1 gang accessory box
code
depth pack
DD1510WH
30mm 20
2 gang accessory box
code
depth pack
DD1520WH
30mm 10
Round conduit adaptor
code
size
pack
DD1720WH
20mm 1
DD1725WH
25mm 1
*Box adaptors
When installing adjustable boxes DD1540 and DD1550, a DD1590 adaptor should
be used at either end of the box.
Where two or more adjustable boxes are being used in line, the spacer included
is for use between boxes and a DD1590 adaptor is used at either end.
MMT2 adaptor
code
size
pack
DD1740WH
MMT2
1
*2 gang
adjustable depth box
code
depth pack
*DD1550WH
32 – 40mm 10
*Accessory box adaptor
code
pack
DD1590WH
1 pair
Each pack contains 2 adaptors
p274
Technical
Information
1 gang data
mounting frame
code
pack
DD1560WH
20
2 gang data
mounting frame
code
pack
DD1570WH
10
Odyssey Bio trunking component chart
Trunking
assembly
End cap
(1 piece)
Coupler
(1 piece)
Internal
bend
(1 piece)
Internal
adjustable
bend
External
bend
(1 piece)
External
adjustable
bend
Flat
angles
(up or
down)
Flat tees
(up or
down)
2 gang
Bio data
mounting
frame
1 gang
Bio data
mounting
frame
Odyssey
trunking
180 x 57mm
DD1B
Pack 1 x 3m
DD1233
Pack 2
DD1213
Pack 1
DD1313
Pack 1
DD1333
Pack 1
DD1353
Pack 1
DD1373
Pack 1
DD1413
Pack 1
DD1433
Pack 1
DD1571
Pack 1
DD1561
Pack 1
Odyssey Bio
Odyssey is available as part of our standard range with Bio antimicrobial protection within the PVC-U material.
antimicrobial trunking
Part M
For boxes that meet
the requirements of
Part M (DDA) please
refer to page 106.
DD1550 is fully adjustable to
47mm. Please see page 311 for
more information.
