6.15
Push-Buttons and Remote Controls
Radio push-buttons and remote
controls enable easy addition
of control points without wiring
work. They are suitable for all
situations : new systems,
renovations or post installation.
These products are included
in Tebis system. They control
both radio output modules as
well as twisted pair products via
TR131A.
Radio Remote Control
These are portable radio
emitters of EIB/KNX standard.
The remote controls are
available in 4, 8 and 24 ways.
Putting Into Service
Allocation of the links is carried
out by TX100GB configurator.
These products also
communicate with twisted pair
products via the TR131A bus
radio / twisted pair
General characteristics of the
radio system
• Frequency : 868.3 MHz
• Range : it is variable
according to the environment :
up to 30m inside, up to 100m
in free air.
Working temperature :
0°C to +45°C
A measurement of the signal
interference is possible by
TX100GB
RF system
• Maximum number of RF
products = 256
• Maximum number of RF input
translations by the media
coupler to twisted pair output
products = 63
For technical details see page
6.36.
KNX Radio Remote Controls
Power supply: CR 2430 3V Lithium Battery Cell (life 3 years)
Unidirectional products: Emitter
Transmission indicated by LED
Functions:
• Start/Stop, Dimming
• Up/Down + Alarm
• Override
• Scenarios
Description
No of Keys
Cat ref.
2 Channel Remote Control
2
TU402
4 Channel Remote Control
4
TU404
6 Way Remote Control
6
TU406
18 Way Remote Control
6 + 1
TU418
TU404
Tebis KNX
