General Catalogue • tebis.KNX
Lighting
Dimmers
TXA210N, TXA210AN,
TXA213N, TXA215
Universal dimmer with automatic
load recognition.
Min/Max level local setting.
Manual mode that allows
dimming even when the bus is
disconnected.
Easy mode: (TX100GB)
Implementation of the channel
dimming actuator scene.
S-mode: (ETS software)
Easy channels features
32 light scenes with a related
scene speed.
Fixing of output state when bus
is disconnected.
Enhanced override modes
(forced).
TXA210N Universal dimmer 1
channel 600W
TXA210AN Universal dimmer 1
channel 300W
TXA213N Universal dimmer 3
channels 300W
3 modes possible :
• 3 channels 3 x 300W
• 2 channels 600W / 300W
• 1 channel 900W
TXA215 Universal dimmer 1
channel 1000W
Dimmer with LCD display
Local setting of the dimming
parameters (min/max, soft ON,
soft OFF, dimming speed) and
light scenes.
8 light scenes that can be
activated locally.
For technical details see page
6.31 - 6.32.
1 Channel Universal Dimmer 600W
Description
Width
Cat ref.
600W Incandescent / Halogen
4 Mod
TXA210N
600VA ELV Halogen associated with electronic or
ferromagnetic transformer
120W LED /dimmable compact fluorescent
1 Channel Universal Dimmer 300W
Description
Width
Cat ref.
300W Incandescent / Halogen
4 Mod
TXA210AN
300VA ELV Halogen associated with electronic or
ferromagnetic transformer
60W LED /dimmable compact fluorescent
3 Channel Universal Dimmer 300W
3 channel dimmer that can be used as 3 x 300W, 600W/300W or 900W, selector on device
Description
Width
Cat ref.
300W Incandescent / Halogen
6 Mod
TXA213N
300VA ELV associated with electronic or
ferromagnetic transformer
60W LED /dimmable compact fluorescent
1 Channel Universal Dimmer 1000W
LCD display used to indicate the dimming level and to set the dimming parameters min, max, diming
speed, soft on, soft off, scenes
Description
Width
Cat ref.
1000W Incandescent / Halogen
6 Mod
TXA215
1000VA ELV Halogen associated with electronic or
ferromagnetic transformer
Output Modules for Variable Lighting (Dimmer Control)
For lighting loads requiring 1/10V dimming signal. Functions include ON/OFF and variation in lighting/
dimmer control.
Description
Width
Cat ref.
3 Outputs 1/10V
4 Mod
TX211A
TXA215
TX211A
TXA213N
TXA210N
TXA210AN
