General Catalogue • tebis.KNX
Automation Products
Automation products provide
commands in form of contacts.
Input information such as rain,
wind, sunrise, sunset, indoor
and outdoor temperature, as
well as commands from remote
telephone interface are received
and forwarded to input modules
for controlling the outputs in the
Tebis system.
Wind detector - helps in
protecting blinds and shutters in
the event of strong wind by
creating a closing command.
Weather station - it includes a
sensor block and a modular unit
for interpretation. It is a
complete system with input
sensor, processing and weather
data transmission.
It also integrates a weekly
programmer equipped with
DCF77 antenna.
Wind Detector
Helps protect blinds in the event of strong wind. Consists of an anenometer and electronic box. Use with
the Tebis system - contact of anenometer can be connected to input module TXA304 and TXA306. (For
further details see page 6.25).
Description
Dimensions
Supply
Cat ref.
dia. x depth (mm)
Level of detection adjustable from 5 to 55km/h
110 x 31
230V AC 50 Hz
TG050
(Factory preset to 25km/h)
Telephone Gateway
3 Inputs, 3 Outputs
• Remote control : 3 relay outputs
• Status indication : for each output
• User friendly voice guide in English
• Remote alarm detection and sending of voice messages to 3 programmed telephone numbers
• Recording of your own messages
• Voice messages for room temperature indication possibility to use together with an answering machine
on the same telephone line
• Personal secret code to limit access to the device
• Timed switch-off of the relay output (from 1 second up to 59h 59min 59sec)
Description
Width (mm)
Supply
Cat ref.
Analog telephone line (PSTN) 48VDC
5 Mod
230VM ±15%
TH020B
3 relay output 5A-250V AC1
50/60 Hz
1 temperature measurement CTN 10 kOhm
2 alarm inputs : 1 input 0-30VAC/DC 5mA min
1 input 0-230V AC 5mA min
Power shutdown detection
Environment
Working temperature : 0/+50°C
Storage temperaure : -20/+70°C
IP 30, IK03
Connection
Flexible 2 x 2.5mm
2
max
Rigid : 2 x 2.5mm
2
max
TG050
TH020B
