General Catalogue • tebis.KNX
KNX Temperature Control Actuator
Thermostat TX320
Continuous room temperature
regulator, featuring real-time
temperature measurement,
capable of sending an
adjustment value to a servo
or actuator, so to achieve the
desired room temperature. It can
control both heating device and
air-conditioners.
Heating ouput, 6 channels
This device is designed for
installation into a hot water
circulation system, to control a
24V valve servo, e.g.: floor
heating facilities. Output
switching utilises a Triac so
that noiseless switching can be
achieved.
Valve Control Servo
This servo has a bus connection,
which can be directly installed
onto the universal valve of the
radiating heaters. The
corresponding valve servo and
motorized device is
controlled via the room
temperature controller.
For technical details see page
6.33.
Thermostat
Features:
• Power supply: 30V DC
• Measuring range: 0ºC to 40ºC
• 3 external contact points used for measuring input terminals, such as window magnetic contact points
Function:
• Heating / Cooling
• 2 step heating - Primary and Supplementary
• Work mode: Comfort, Standby, Night time, Frost / Overheat protection
• Switch, Light dimming, Blinds control
Description
Dimensions
Cat ref.
h x w x d (mm)
Thermostat
27 x 84 x 80
TX320
Floor temperature sensor for TX320
-
EK087
Outside temperature sensor for TX320
-
EK088
Heating Valve Controller (6 Channels)
Features:
• Power supply: 230V power socket
• System voltage of 30V DC
• 6 channel for 24V heating valves (max 13 valves/channel)
• 6 channel output
Function:
• Adjusting value in %
• Override service
• Summer operation
Description
Dimensions
Cat ref.
h x w x d (mm)
Heating valve controller (6 channel)
70 x 755 x 302
TX206H
TX320
TX206H
