General Catalogue • Consumer Units
VM02CE
VA10MT
VMHBL
VMLOCK
Cable Protector Plate
Cable Clamp
Health & Safety Lock
Key Lock
Grommets & Grommet Strip
Provides a safe and smooth
entry for cables into the rear of
the consumer unit.
Designed to fit into the aperture
left by the removal of a rear
knockout on the Design 10
or Design 30 Consumer Unit.
(Included as standard with the
Design 30 board)
VM01CE:
Simply insert protector
plate and bend over tabs inside
board.
VM02CE:
Break away sections
as required and simply push into
place.
Secures supply cables on
entry to main incoming device,
eliminating any movement of the
cables being transmitted to the
terminals.
Simply insert supply cables
through clamp into incoming
device & secure with fixing
provided.
(Included as standard with the
Design 30 board)
Provides the ability to lock
the consumer unit during the
installation process.
Can only be used with Design 30
Consumer Units.
Allows door to be lockable.
Simply remove the centre of the
lock surround and the knockout
behind, and fit lock.
Can only be used with Design 30
Consumer Units.
Grommets for protecting against
sharp edges on knockouts
Description
Quantity
Cat ref.
Cable Protector Plate (Metal)
1
VM01CE
Cable Protector Plate (Insulated)
5
VM02CE
Description
Cat ref.
Cable Clamp for Meter Tails
VA10MT
Description
Cat ref.
Health & Safety Padlock Bracket
VMHBL
Padlock
JK25A
Description
Cat ref.
Design 30 Door Locking Kit
VMLOCK
Description
Quantity
Cat ref.
Grommet strip 5 metres
1 Strip
VM05GS
38mm open grommet for use with VMLF* back boxes
10
VMGROM
Accessories
