General Catalogue • Consumer Units
VML11010
Design 10 Dual Row Consumer Unit
Conforms to BS EN 61439-3
Including Annex ZB (16kA
Rating).
Enclosures come supplied with
a full metal DIN rail, earth and
neutral connections along with
incoming device(s), busbar,
marking labels and instructions.
For dimensions see page 1.21.
Knockouts located top, bottom
and rear of base - See page
1.21.
Switch Disconnector - Dual Row
Size
Cat ref.
6+6 Way 100A Switch Disconnector
3
VML10606
10+10 Way 100A Switch Disconnector
4
VML11010
14+14 Way 100A Switch Disconnector
5
VML11414
20+20 Way 100A Switch Disconnector
7
VML12020
RCCB Incomer - Dual Row
6+6 Way 100A 30mA RCCB Incomer
3
VML30606H
Split Load - Dual Row
4+6 Way 100A Switch 2x63A 30mA RCCB
3
VML746H
8+10W 100A Switch 2x63A 30mA RCCB
4
VML70810H
12+14W 100A Switch 2x63A 30mA RCCB
5
VML71214H
18+20W 100A Switch 2x63A 30mA RCCB
7
VML71820H
4+6 Way 100A Switch 2x80A 30mA RCCB
3
VML846H
8+10W 100A Switch 2x80A 30mA RCCB
4
VML80810H
12+14W 100A Switch 2x80A 30mA RCCB
5
VML81214H
18+20W 100A Switch 2x80A 30mA RCCB
7
VML81820H
High Integrity - Dual Row
HI Configurable 8+10 Way 100A Switch 2x63A
4
VML70810CU
HI Configurable 12+14 Way 100A Switch 2x63A
5
VML71214CU
HI Configurable 18+20 Way 100A Switch 2x63A
7
VML71820CU
HI Configurable 8+10 Way 100A Switch 2x80A
4
VML80810CU
HI Configurable 12+14 Way 100A Switch 2x80A
5
VML81214CU
HI Configurable 18+20 Way 100A Switch 2x80A
7
VML81820CU
Multi Tariff - Dual Row
10 Way Split Load 5+5 100A Switch 2x63A RCCB
4
VML755714H
1x63A RCCB Incomer 14 Ways
Sw/D/I
RCCB
RCCB
Connect
RCCB
Sw/D/I
RCCB
RCCB
Sw/D/I
RCCB
RCCB
RCCB
Sw/D/I
Connect
Switch Disconnector
RCCB Incomer
High Integrity
Split Load
Multi Tariff
Dual Row Consumer Units
Design 10
