1.5
VM716C
VM878R
Split Load
High Integrity
Metal split load and configurable
enclosures, single row from 6 to
16 outgoing ways.
Enclosures come supplied with a
full metal DIN rail and 2 RCCBs
and full complement of earth
and neutral terminals along
with marking labels, busbar,
instructions, rear cable protector
plate and meter tail clamp.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts - see page 1.20.
Metal split load and configurable
enclosures with ability to protect
selected circuits with RCBOs
and remainder of circuits split
accross two RCCBs. Single row
from 10 to 16 outgoing ways.
Enclosures come supplied with a
full metal DIN rail and 2 RCCBs
and full complement of earth
and neutral terminals along
with marking labels, busbar,
instructions, rear cable protector
plate and meter tail clamp.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts see page 1.20.
Size
Cat ref.
Cat ref. with
Description
knockouts
6 Way Split Load 3+3 100A Switch 2x63A 30mA RCCB
4
VM733H VM733HK
10 Way Split Load 5+5 100A Switch 2x63A 30mA RCCB
5
VM755H VM755HK
12 Way Split Load 6+6 100A Switch 2x63A 30mA RCCB
6
VM766H VM766HK
10 Way Split Load Configurable 100A Switch 2x 63A 30mA RCCB
5
VM710C VM710CK
16 Way Split Load Configurable 100A Switch 2x 63A 30mA RCCB
7
VM716C VM716CK
10 Way Split Load 5+5 100A Switch 2x80A 30mA RCCB
5
VM855H VM855HK
12 Way Split Load 6+6 100A Switch 2x80A 30mA RCCB
6
VM866H VM866HK
10 Way Split Load Configurable 100A Switch 2x 80A 30mA RCCB
5
VM810C VM810CK
16 Way Split Load Configurable 100A Switch 2x80A 30mA RCCB
7
VM816C VM816CK
Size
Cat ref.
Cat ref. with
Description
knockouts
10 Way High Integrity Split Load Configurable
5
VM710CU
VM710CUK
100A Switch 2x 63A 30mA RCCB
16 Way High Integrity Split Load Configurable
7
VM716CU
VM716CUK
100A Switch 2x 63A 30mA RCCB
10 Way High Integrity Split Load Configurable
5
VM810CU
VM810CUK
100A Switch 2x 80A 30mA RCCB
16 Way High Integrity Split Load Configurable
7
VM816CU
VM816CUK
100A Switch 2x 80A 30mA RCCB
10 Way High Integrity 5+4+1
5
VM754R
VM754RK
100A Switch 2x 63A 30mA RCCB + 6A RCBO
16 Way High Integrity Split Load 7+8+1
7
VM778R
VM778RK
100A Switch 2x 63A 30mA RCCB + 1x RCBO
10 Way High Integrity 5+4+1
5
VM854R
VM854RK
100A Switch 2x 80A 30mA RCCB + 6A RCBO
16 Way High Integrity Split Load 7+8+1
7
VM878R
VM878RK
100A Switch 2x 80A 30mA RCCB + 1x RCBO
14 Way Split Load 6+6+2 100A Switch
7
VM8662 VM8662K
2x 80A 30mA RCCB plus 1x 40A 30mA RCCB
VM918C
Multi Tariff
Metal switch disconnector
incomer enclosures, single row,
12 or 18 outgoing ways.
Enclosures come supplied with a
full metal DIN rail, multiple switch
disconnector incomers and full
complement of earth and neutral
terminals along with marking
labels, busbar, instructions, rear
cable protector plate and meter
tail clamp.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts - see page 1.20.
Size
Cat ref.
Cat ref. with
Description
knockouts
18 Way Twin Tariff Configurable 2x100A Switch
7
VM918C VM918CK
12 Way Multi Tariff 6+5+1 2x100A 1x63A Switch
6
VM9651 VM9651K
Sw/D/I
RCCB
RCCB
Sw/D/I
RCCB
RCCB
Sw/D/I
Sw/D/I
Sw/D/I
Sw/D/I
Sw/D/I
Consumer
Units
