General Catalogue • Consumer Units
VML206
VML310H
VML712TG
Switch Disconnector Incomer
RCCB Incomer
Time Delayed RCCB Incomer
Metal switch disconnector
incomer enclosures, single row
from 2 to 20 outgoing ways.
Enclosures come supplied with
a full metal DIN rail, 63A or 100A
switch disconnector incomer
and full complement of earth
and neutral terminals along with
marking labels, busbar and
instructions.
Recommended for use with TT
systems when utilising RCBO on
outgoing circuits.
Hager also recommend the use
of cable clamp (
VA10MT
) for
use on TT systems. Available as
accessory.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Metal RCCB incomer enclosures,
single row from 2 to 14 outgoing
ways.
Enclosures come supplied with
a full metal DIN rail, 40A, 63A
or 100A 30mA RCCB incomer
and full complement of earth
and neutral terminals along with
marking labels, busbar and
instructions.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Metal RCCB incomer enclosures,
single row 12 outgoing ways.
Enclosures come supplied
with a full metal DIN rail 100A
100mA time delayed and 63A
30mA RCCB incomers and full
complement of earth and neutral
terminals along with marking
labels, busbar, meter tail clamp
and instructions.
Recommended for use with TT
systems.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Description
Size
Cat ref.
2 Way 63A Switch Disconnector Incomer
2
VML202
6 Way 63A Switch Disconnector Incomer
3
VML206
6 Way 100A Switch Disconnector Incomer
3
VML106
10 Way 100A Switch Disconnector Incomer
4
VML110
14 Way 100A Switch Disconnector Incomer
5
VML114
20 Way 100A Switch Disconnector Incomer
7
VML120
Description
Size
Cat ref.
2 Way 40A 30mA RCCB Incomer
2
VML402H
6 Way 63A 30mA RCCB Incomer
3
VML406H
6 Way 100A 30mA RCCB Incomer
3
VML306H
10 Way 63A 30mA RCCB Incomer
4
VML410H
10 Way 100A 30mA RCCB Incomer
4
VML310H
14 Way 100A 30mA RCCB Incomer
5
VML314H
Description
Size
Cat ref.
12 Way Configurable 100A 100mA Time Delay RCCB 63A 30mA RCCB 5
VML712TG
12 Way 100A 100mA Time Delay RCCB 2x63A 30mA RCCB
6
VML766TG
Sw/D/I
RCCB
RCCB
RCCB
RCCB
RCCB
RCCB
Design 10
