General Catalogue • Consumer Units
VM206
VM310H
Switch Disconnector
RCCB Incomer
Metal switch disconnector
incomer enclosures, single row
from 2 to 20 outgoing ways.
Enclosures come supplied with
a full metal DIN rail, 63A or 100A
switch disconnector incomer
and full complement of earth
and neutral terminals along
with marking labels, busbar,
instructions, rear cable protector
plate and meter tail clamp.
Recommended for use with TT
systems when utilising RCBO on
outgoing circuits.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts - see page 1.20.
Metal RCCB incomer enclosures,
single row from 2 to 14 outgoing
ways.
Enclosures come supplied with
a full metal DIN rail, 40A, 63A
or 100A 30mA RCCB incomer
and full complement of earth
and neutral terminals along
with marking labels, busbar,
instructions, rear cable protector
plate and meter tail clamp.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts - see page 1.20.
Size
Cat ref.
Cat ref. with
Description
knockouts
2 Way 63A Switch Disconnector Incomer
2
VM202
VM202K
6 Way 63A Switch Disconnector Incomer
3
VM206
VM206K
6 Way 100A Switch Disconnector Incomer
3
VM106
VM106K
10 Way 100A Switch Disconnector Incomer
4
VM110
VM110K
14 Way 100A Switch Disconnector Incomer
5
VM114
VM114K
20 Way 100A Switch Disconnector Incomer
7
VM120
VM120K
Size
Cat ref.
Cat ref. with
Description
knockouts
2 Way 40A 30mA RCCB Incomer
2
VM402H
VM402HK
6 Way 63A 30mA RCCB Incomer
3
VM406H
VM406HK
6 Way 100A 30mA RCCB Incomer
3
VM306H
VM306HK
10 Way 63A 30mA RCCB Incomer
4
VM410H
VM410HK
10 Way 100A 30mA RCCB Incomer
4
VM310H
VM310HK
14 Way 100A 30mA RCCB Incomer
5
VM314H
VM314HK
VM712TG
Time Delayed RCCB Incomer
Metal RCCB incomer enclosures,
single row 12 outgoing ways.
Enclosures come supplied
with a full metal DIN rail 100A
100mA time delayed and 63A
30mA RCCB incomers and full
complement of earth and neutral
terminals along with marking
labels, busbar, instructions, rear
cable protector plate and meter
tail clamp.
Recommended for use with TT
systems.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12
For dimensions see page 1.20
All boards contain rear cable
entry, boards with knockouts
also contain top & bottom
knockouts - see page 1.20.
Size
Cat ref.
Cat ref. with
Description
knockouts
12 Way Configurable 100A 100mA Time Delay RCCB 63A 30mA RCCB 5
VM712TG VM712TGK
12 Way 100A 100mA Time Delay RCCB 2*63A 30mA RCCB
6
VM766TG VM766TGK
Sw/D/I
RCCB
RCCB
RCCB
RCCB
RCCB
RCCB
