General Catalogue • Consumer Units
VM11010
Design 30 Dual Row Consumer Unit
Conforms to
BS EN 61439-3 Including Annex
ZB (16kA Rating)
Enclosures come supplied with
a full metal DIN rail, earth and
neutral connections along with
incoming device(s), busbar, cable
protector plate, grommet strip,
cable clamp, marking labels and
instructions
Knockouts (where applicable)
located top, bottom and rear of
base - See page 1.21.
For dimensions see page 1.21.
Size
Cat ref.
Cat Ref. with
Switch Disconnector - Dual Row
Knockouts
6+6 Way 100A Switch Disconnector
3
VM10606
VM10606K
10+10 Way 100A Switch Disconnector
4
VM11010
VM11010K
14+14 Way 100A Switch Disconnector
5
VM11414
VM11414K
20+20 Way 100A Switch Disconnector
7
VM12020
VM12020K
RCCB Incomer - Dual Row
6+6 Way 100A 30mA RCCB Incomer
3
VM30606H VM30606HK
Split Load - Dual Row
8+10W 100A Switch 2x63A 30mA RCCB
4
VM70810H VM70810HK
12+14W 100A Switch 2x63A 30mA RCCB
5
VM71214H VM71214HK
18+20W 100A Switch 2x63A 30mA RCCB
7
VM71820H VM71820HK
4+6 Way 100A Switch 2x63A 30mA RCCB
3
VM746H
VM746HK
8+10W 100A Switch 2x80A 30mA RCCB
4
VM80810H VM80810HK
12+14W 100A Switch 2x80A 30mA RCCB
5
VM81214H VM81214HK
18+20W 100A Switch 2x80A 30mA RCCB
7
VM81820H VM81820HK
4+6 Way 100A Switch 2x80A 30mA RCCB
3
VM846H
VM846HK
High Integrity - Dual Row
HI Configurable 8+10 Way 100A Switch 2x63A
4
VM70810CU VM70810CUK
HI Configurable 12+14 Way 100A Switch 2x63A
5
VM71214CU VM71214CUK
HI Configurable 18+20 Way 100A Switch 2x63A
7
VM71820CU VM71820CUK
HI Configurable 8+10 Way 100A Switch 2x80A
4
VM80810CU VM80810CUK
HI Configurable 12+14 Way 100A Switch 2x80A
5
VM81214CU VM81214CUK
HI Configurable 18+20 Way 100A Switch 2x80A
7
VM81820CU VM81820CUK
Multi Tariff - Dual Row
10 Way Split Load 5+5 100A Switch 2x63A RCCB
4
VM755714H VM755714HK
1x63A RCCB Incomer 14 Ways
Sw/D/I
RCCB
RCCB
Connect
RCCB
Sw/D/I
RCCB
RCCB
Sw/D/I
RCCB
RCCB
RCCB
Sw/D/I
Connect
Switch Disconnector
RCCB Incomer
High Integrity
Split Load
Multi Tariff
Dual Row Consumer Units
Design 30
