25 / 430
Sales Service Centre • 01952 675612 Technical Support Helpline • 01952 675689
1.9
VML716C
VML878R
VML918C
Split Load
High Integrity
Multi Tariff
Metal split load and configurable
enclosures, single row from 6 to
16 outgoing ways.
Enclosures come supplied with a
full metal DIN rail and 2 RCCBs
and full complement of earth
and neutral terminals along with
marking labels, busbar and
instructions.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Metal split load and configurable
enclosures with ability to protect
selected circuits with RCBOs
and remainder of circuits split
accross two RCCBs. Single row
from 10 to 16 outgoing ways.
Enclosures come supplied with a
full metal DIN rail and 2 RCCBs
and full complement of earth
and neutral terminals along with
marking labels, busbar and
instructions.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Metal switch disconnector
incomer enclosures, single row,
12 or 18 outgoing ways.
Enclosures come supplied with a
full metal DIN rail, multiple switch
disconnector incomers and full
complement of earth and neutral
terminals along with marking
labels, busbar and instructions.
Conforms to BS EN 61439-3
Including Annex ZB (16kA rating).
For accessories see page 1.12.
For dimensions see page 1.20.
All Design 10 boards contain top,
bottom & rear knockouts - see
page 1.20.
Description
Size
Cat ref.
6 Way Split Load 3+3 100A Switch 2x63A 30mA RCCB
4
VML733H
10 Way Split Load 5+5 100A Switch 2x63A 30mA RCCB
5
VML755H
12 Way Split Load 6+6 100A Switch 2x63A 30mA RCCB
6
VML766H
10 Way Split Load Configurable 100A Switch 2x 63A 30mA RCCB
5
VML710C
16 Way Split Load Configurable 100A Switch 2x 63A 30mA RCCB
7
VML716C
10 Way Split Load 5+5 100A Switch 2x80A 30mA RCCB
5
VML855H
12 Way Split Load 6+6 100A Switch 2x80A 30mA RCCB
6
VML866H
10 Way Split Load Configurable 100A Switch 2x80A 30mA RCCB
5
VML810C
16 Way Split Load Configurable 100A Switch 2x80A 30mA RCCB
7
VML816C
Description
Size
Cat ref.
10 Way High Integrity Split Load Configurable
5
VML710CU
100A Switch 2x63A 30mA RCCB
12 Way High Integrity Split Load Configurable
6
VML712CU
100A Switch 2x63A 30mA RCCB
16 Way High Integrity Split Load Configurable
7
VML716CU
100A Switch 2x63A 30mA RCCB
10 Way High Integrity Split Load Configurable
5
VML810CU
100A Switch 2x80A 30mA RCCB
16 Way High Integrity Split Load Configurable
7
VML816CU
100A Switch 2x80A 30mA RCCB
10 Way High Integrity 5+4+1 100A Switch
5
VML754R
2x63A 30mA RCCB + 6A RCBO
16 Way High Integrity 7+8+1 100A Switch
7
VML778R
2x63A 30mA RCCB + 6A RCBO
10 Way High Integrity 5+4+1 100A Switch
5
VML854R
2x80A 30mA RCCB + 6A RCBO
16 Way High Integrity 7+8+1 100A Switch
7
VML878R
2x80A 30mA RCCB + 6A RCBO
14 Way Split Load 6+6+2 100A Switch
7
VML8662
2x80A 30mA RCCB + 40A 30mA RCCB
Description
Size
Cat ref.
18 Way Twin Tariff Configurable 2x100A Switch
7
VML918C
12 Way Multi Tariff 6+5+1 2x100A 1x63A Swtich
6
VML9651
Sw/D/I
RCCB
RCCB
Sw/D/I
RCCB
RCCB
Sw/D/I
Sw/D/I
Sw/D/I
Sw/D/I
Sw/D/I
