1.18

General Catalogue • Consumer Units

Consumer Unit

Accessories

The Hager consumer unit has

been designed to be the most

versatile consumer unit available

on the market today.

The accessories below can be

used to customise standard

consumer units and enclosures

to almost any configuration.

Description

Pack qty

Cat ref. Cat ref.

Plain

Glazed

1 Module busbar blank

25

JK01B

100 Amp terminal block (MCB profile) fits directly onto busbar

1

KRN190

(cable capacity 50mm

2

)

Surge protecion kit

1

VA02SPD

100A Main Switch

1

SPN290

Neutral link

1

VAN00

Door Locking kit

1

VAL00

Incoming tail connection kit

1

VAM00

Dual tariff link kit

1

VAK0D

Split load link kit

1

VAK0S

Triple tariff link kit

1

VAK0T

8 Module busbar

1

VAB08

12 Module busbar

1

VAB12

16 Module busbar

1

VAB16

21 Module busbar

1

VAB21

14 Way SP&SN insulated busbar

1

VAB14N

Terminal bar support clips

5

VAT00

Terminal bar 2 way

1

VAT02

Terminal bar 3 way

1

VAT03

Terminal bar 4 way

1

VAT04

Terminal bar 5 way

1

VAT05

Terminal bar 6 way

1

VAT06

Terminal bar 7 way

1

VAT07

Terminal bar 8 way

1

VAT08

Terminal bar 9 way

1

VAT09

Terminal bar 10 way

1

VAT10

Terminal bar 11 way

1

VAT11

Terminal bar 12 way

1

VAT12

Terminal bar 13 way

1

VAT13

Terminal bar 14 way

1

VAT14

Terminal bar 15 way

1

VAT15

Terminal bar 16 way

1

VAT16

Terminal bar 17 way

1

VAT17

Terminal bar 18 way

1

VAT18

Terminal bar 19 way

1

VAT19

Terminal bar 20 way

1

VAT20

Terminal bar 21 way

1

VAT21

Terminal bar 22 way

1

VAT22

Terminal bar 23 way

1

VAT23

Terminal bar 24 way

1

VAT24

Label pack

1

VAP00

Seal strip size 3 - 8 module

2

VAR3S

Seal strip size 4 - 12 module

2

VAR4S

Seal strip size 5 - 16 module

2

VAR5S

Seal strip size 6 - 22 module

2

VAR6S

VAN00

VAM00

JK01B

VAB08
