General Catalogue • Consumer Units • Technical
Design 30
Dimensions (mm)
Enclosure Size
2
3
4
5
6
7
A
149 221 293 364 400 472
B
240 240 240 240 240 240
C
102.5 102.5 102.5 102.5 102.5 102.5
Number of Knockouts
Top Face 30 x 15 (mm)
2
2
2
2
2
2
Top Face 40 x 30 (mm)
0
2
4
4
6
6
Back 100 x 50 (mm)
1
1
1
3
3
3
Bottom Face 30 x 15 (mm)
2
3
4
4
5
5
Design 10
Dimensions (mm)
Enclosure Size
2
3
4
5
6
7
A
155 227 299 370 406 478
B
246 246 246 246 246 246
C
83
83
83
83
83
83
D
100 100 100 100 100 100
Number of Knockouts
Top Face 30 x 15 (mm)
2
2
2
2
2
2
Top Face 40 x 30 (mm)
0
2
4
4
6
6
Back 100 x 50 (mm)
1
1
1
3
3
3
Bottom Face 30 x 15 (mm)
2
3
4
4
5
5
B
A
D
C
B
A
C
Consumer Unit Dimensions
Design 10 & Design 30
