Consumer Unit Dimensions
Design Range Dual Row & Flush
Dual Row Design 10
Dimensions (mm)
Enclosure Size
3
4
5
6
7
A
227 299 370 406 478
B
486 486 486 486 486
C
83
83
83
83
83
D
100 100 100 100 100
Number of Knockouts
Top Face 30 x 15 (mm)
2
2
2
2
2
Top Face 40 x 30 (mm)
2
4
4
6
6
Back 100 x 50 (mm)
2
2
6
6
6
Bottom Face 30 x 15 (mm)
3
4
4
5
5
B
A
C
D
Dual Row Design 30
Dimensions (mm)
Enclosure Size
3
4
5
6
7
A
221 293 364 400 472
B
480 480 480 480 480
C
102.5 102.5 102.5 102.5 102.5
Number of Knockouts
Top Face 30 x 15 (mm)
2
2
2
2
2
Top Face 40 x 30 (mm)
2
4
4
6
6
Back 100 x 50 (mm)
2
2
6
6
6
Bottom Face 30 x 15 (mm)
3
4
4
5
5
Flush Design 10
Dimensions (mm)
Enclosure Size
4
5
6
7
A
282 282 282 282
B
335 407 443 515
C
32
32
32
32
D
298 370 406 478
E
252 252 252 252
F
72
72
72
72
Number of Knockouts
Top Face 50 x 20 (mm)
4
5
6
7
Bottom Face 50 x 20 (mm)
4
5
6
7
Back 100 x 50 (mm)
2
2
2
3
Left Face 20.8 (mm)
1
1
1
1
A
C
B
