Consumer Unit Dimensions
Garage Units & IP55 Weather Proof
Skeleton (Mantel)
Dimensions (mm)
Width Height Depth Fixing Centres (mm)
331 221 74
320
Garage Units & IP55 Weather Proof
Dimensions (mm)
Width Height Depth
VE24H 180 110 82
GD24H 168 193 113
VW110G 310 302 151
VW310G 310 302 151
VW620G 310 427 151
Torque Settings
Pz No. (mm)
Cables >1.5mm
2
Tightening torque (N.m)
Cables ≤1.5mm
2
Tightening torque (N.m)
Cable Stripping
(mm)
Single Cable Multi Cables Single Cable Multi Cable
Consumer unit terminals
Earth and neutral terminal bars
2
6.5
2
2
1.5
1.5
10
Isolation
SB switch disconnectors
2
6.5
3.6
3.6
3.6
3.6
15
Circuit protection
MTN MCB
2
6.5
2.8
2.8
2.8
2.8
13
NBN/NCN/NDN MCB
2
6.5
2.8
2.8
2.8
2.8
13
RCBO
2
5.5
2.1
2.1
2.1
2.1
13
RCCB
2
5.5
2.8
2.8
2.8
2.8
13
Width
Depth
Height
Width
Depth
Height
Consumer
Units
