invicta 3 Type B Distribution Boards
250A Meter Packs & Dual Meter Incomer Kits
Dual Meter 250A Incomer Kits
(note: these dual meter incomer kits will only fit the 250A board(s)
Each meter pack contains:
1x Incoming Switch.
2 of each of the following: Meter, 3 Pole CT Block, 3 x Fuses & Carriers on DIN rail, Wiring Loom, Incoming
Shroud, Instructions (including torque settings for electrical connections), Off Set Incoming Links, Neutral
Connection Block and Extension Box with Glazed Doors.
Description
Cat ref.
Dual kWh Meter Pack 250A Incomer Pulsed
JKD250BKWP
Dual Multifunction Meter Pack 250A Incomer Pulsed
JKD250BMP
Dual Multifunction Meter Pack 250A Incomer ModBus
JKD250BMM
250A Meter Packs
(note: these incomer kits will only fit the 250A board(s)
These kits fit into the main distribution board.
Each meter pack contains:
Meter, 3 Pole CT Block, 3 x Fuses & Carriers on DIN rail, Wiring Loom, Incoming Shroud, Instructions
(including torque settings for electrical connections).
Description
Cat ref.
Digital Multifunction Meter Pack Pulsed
JK240MP
Digital Multifunction Meter Pack ModBus
JK240MJ
kWh Meter Pack Pulsed
JK242BA
25A
32A
40A
50A
63A
NBN125A NBN132A NBN140A NBN150A NBN163A
NBN325A NBN332A NBN340A NBN350A NBN363A
NCN125A NCN132A NCN140A NCN150A NCN163A
NCN325A NCN332A NCN340A NCN350A NCN363A
NDN125A NDN132A NDN140A NDN150A NDN163A
NDN325A NDN332A NDN340A NDN350A NDN363A
RCBO Single Pole
Sensitivity 30mA (10kA) Type C
Current rating
Cat ref.
6A
ADC106
10A
ADC110
16A
ADC116
20A
ADC120
25A
ADC125
32A
ADC132
40A
ADC140
45A
ADC145
50A
ADC150
RCBO Single Pole
Sensitivity 30mA (10kA) Type B
Current rating
Cat ref.
6A
ADB106
10A
ADB110
16A
ADB116
20A
ADB120
25A
ADB125
32A
ADB132
40A
ADB140
45A
ADB145
50A
ADB150
JKD250BMP (shown fitted with
2x JK208BG distribution boards
(not incldued)
