690

FLOOR SYSTEMS

SCREEDED

Cablelink Plus Screed

Technical

TOP TIPS

l

The number and location of boxes will depend on the end user

requirements

l

If the furniture layout is available, a floor box should be considered

for each workstation or desk

l

If the final furniture layout is not available as a general guide the

minimum recommended distribution is one floor box for every

10m², and the maximum being one floor box per 4m²

Cablelink Plus Screed System

Cable Capacity Guide

The cable factor table below is based on the 17th Edition of the

IET Wiring Regulation (BS 7671) and must be regarded only as

a guideline. Care should be taken in selecting adequate trunking

sections taking into consideration the number and size of cables

involved and construction of the junction box. It is recommended

that the initial design of trunking installations include adequate

provision for future wiring. To determine the size of the trunking

required, multiply the quantities of each size of conductor and

appropriate factor from Table A and compare the total with the

capacity unit figure in the appropriate Table B.

TABLE A – CABLE FACTORS

CABLE TYPE

CSA

CABLE FACTOR

POWER CABLES

PVC Stranded

1.5mm²

8.6

2.5mm²

12.6

4mm²

16.6

6mm²

21.2

10mm²

35.3

16mm²

47.8

25mm²

73.9

Twin & Earth

2.5mm²

86

4mm²

99

6mm²

148

DATA CABLES

Cat 5E UTP

5.5mm dia

30.2

Cat 5E STP

6.0mm dia

36

Cat 6 UTP

6.5mm dia

42.2

Cat 6 STP

7.0mm dia

49

Cat 6A

8.0mm dia

64

Sample calculation

To estimate the total number of cables that can be accommodated

with a 100 x 38mm ducting:

Step 1

Pick the factor from Table B corresponding to

100 x 38 = 1563

Step 2

Select the size of the cable that needs to be pulled

through the trunking and its corresponding factor from

Table A e.g. 4mm

2

stranded = 16.6

Step 3

No. of cables = Value from (Table B / Table A)

e.g. 1563/16.6 = 94 Cables.

TABLE B – METAL SCREED DUCTING CABLING CAPACITY

SIZE

(MM)

COMPARTMENT

SIZE

CAPACITY

100%

CAPACITY

(45% FILL)

100 x 38

100 x 38 (1 comp)

3474

1563

225 x 38

112 x 25 (2 comp)

75 x 38 (3 comp)

3940

2613

1773

1176

250 x 38

13 x 38 (3 comp)

2909

1309

275 x 38

91 x 38 (3 comp)

3206

1443

300 x 38

100 x 38 (1 comp)

3503

1576

Cablelink Plus Screed System ducting complies with

BS EN 50085-1:2005 and BS EN 50085-2-2:2008.

The above table gives the available capacity units on 45% factor,

applied to the internal wiring area.

Carpet Cut out Dimensions

A

B

A

B

C

D

14

14

The table below shows the sizes required for the carpet lid infill

and carpet tile cut out for the Cablelink Plus Screed Floorboxes.

LID LIST

NUMBER

CARPET LID INFILL

DIMENSIONS

(mm)

A

B

CXL100

152

93

CXL265

219

251

CXL340

219

326

CUJL200

188

188

CUJL265

253

253

CUJL240

328

328

DUCTING CABLE CAPACITY – DATA CABLES

DUCTING

CAPACITY mm²

60MM DUCTING

90MM DUCTING

1025

2300

NOMINAL CABLE

DIAMETER mm²

NUMBER OF CABLES

60mm DUCTING

90mm DUCTING

@50% @75% @50% @75%

5.5

17

25

38

57

6

14

21

32

48

6.5

12

18

27

41

7

10

15

23

35

8

8

12

17

26

BASE LIST

NUMBER

BOX CARPET CUT

OUT DIMENSIONS

(mm)

C

D

CUB100

100

100

CUB265

265

265

CUB340

340

340

CUJ200

200

200

CUJ265

265

265

CUJ240

340

340
