FLOOR SYSTEMS
SCREEDED
Cablelink Plus Screed
Technical
Cablelink Plus Screed Service Box
Materials
UL94 V2 rated nylon, Pre-galvanised
steel.
Strength
The floor outlet boxes are capable of
resisting minor accidental loading when
rigidly supported under the outer rim of
the cover frame.
Fire
The outer casing of the floor outlet box is
manufactured from metal and is non-
combustible. The 8mm recess frame and
lid assembly is made from UL94 V2 rated
nylon the 12mm recess frame and lid
assembly is manufactured from metal and
is non corrosive.
Chemical resistance
Non corrosive.
Water absorption
The floor outlet boxes are for use in
situations where the cleaning method
used does not result in the formation
of pools of liquid or soaking of the floor
surface.
Degree of protection
Enclosure classification of IP2X
when installed in accordance with the
instructions set out in the installation
guide.
Ambient Temperature Range
MINIMUM
MAXIMUM
Handling and storage
-5°C
60°C
During installation
-5°C
60°C
Operating
-5°C
40°C
Average not to exceed 35°C in any 24 hour period.
RAL Colours
Grey (GRY) = RAL 7011
PVCu Ducting and Accessories:
Manufacture
Duct straight lengths are extruded from 100%
recycled PVCu. Fittings are formed by injection
moulding*.
Appearance
All PVCu duct and accessories are normally
smooth, matt white finish.
Strength
Heavy gauge, medium impact resistance
under normal conditions.
Fire
Non flame propagating. Class 1 spread of
flame.
Chemical resistance
Non-corrosive and not affected by sea water.
Excellent resistance to mineral acids, alkalis
and detergents but liable to attack from
solvents such as alcohol, ketones, aromatics
and hydrocarbons.
Vermin
Resistant to vermin and termites.
Thermal
Lower and upper limit of range of ambient
temperature from -5°C to 60°C. All products
are designed to accommodate local thermal
expansion and fitting instructions cover
differential movement at the interface with the
building fabric. Thermal expansion co-efficient:
5.5 x 10-5/°C.
Electrical
Duct is non-conductive.
Dielectric strength: 40kV/mm in DBP
17kV/mm in tx oil.
Volume resistivity: >1014
Ω
cm.
Durability
The product is stable within the terms and
conditions described above and will maintain
its performance characteristics.
Workability
The duct is light weight and can be readily
cut with hand tools. Short lengths can be
readily incorporated and there is low wastage
of material. Components and joints can be
solvent welded together where necessary.
Metal Duct and Accessories
Material
Pre-galvanised sheet steel.
Standard thickness
1.2mm. Standard 1mm available on request.
Standard length
2.44 metres.
No. of compartments
1, 2 or 3 compartments.
Standard depth
38mm (Different depths are available on
request).
Couplers have to be ordered separately.
Pre-cut lengths can be arranged, subject to price confirmation and
availability.
Cablelink Plus Screed System
* based on 2014 consumption
