Echo™ Transmitters
Description
The Elements Echo Transmitters are part of an innovative range of entirely
wireless, batteryless and self powered switches. The Elements Echo Transmitters
communicate with Echo receivers to switch mains power. Elements Echo
Transmitters send an RF signal at 868.3 MHz, the unique feature of these transmitters
is the signal transmission is made with no need for mains power or batteries.
Frontplate and Module Installation
PATTRESS
MODULE PLATE
LATCHES
TRANSMITTER MODULE FRONTPLATE
Dimensions (mm)
86
86
9.65
3.00
Standards and approvals
BS EN 60669-1, BS EN 60669-2-1,
ESTI EN 301 489-1 & -3, ESTI EN 61000-6-2,
ESTI EN 300 220-3, EN 60950-1
TECHNICAL SPECIFICATION
PHYSICAL
OPERATING TEMPERATURE
-5°C + 40°C
OPERATING FREQUENCY:
868.3 MHz
IP RATING
IP2X
MAX INSTALLATION ALTITUDE
2000m
Mounting Transmitters
l All transmitters can be mounted to any 1
gang back box
l All transmitters can be mounted directly to
the wall surface
Features
l 16 standard finishes
l Many more customized
combinations of standard colours,
materials and finishes available
l Bespoke colour materials and
finishes available via the Design
Service
l Wireless and batteryless, using
RF technology with ranges up to
30M in ideal conditions
l The transmitters are quick and
easy to install with no need for
cabling from the switch to the
lighting circuit
l See the Echo range for available
receivers
