501
Electronic Dimmers
LOAD RATING AND TYPE
Leading Edge Dimmers
K34100
K34101 & K34102 (per gang)
GLS/ Tungsten Filament, Mains Tungsten Halogen
40 - 500W
40 – 300W
Mains dimmable LED lamp for incandescent replacement
6 - 150W Max.12 lamps
6 - 120W Max. 12 lamps
ELV Tungsten Halogen with dimmable Ferro-magnetic transformer
35 - 400VA
35 - 240VA
Trailing Edge Dimmers
K34103
K34104 & K34105 (per gang)
GLS/ Tungsten filament, Mains Tungsten Halogen
25 – 500W
25 – 300W
ELV Tungsten Halogen with Dimmable Electronic Transformer
35 – 500VA
35 – 300VA
Dimmable LED Driver
*4-150W
(Max 5 LED drivers only)
*4-120W
(Max 5 LED drivers only)
Note:
1. Do not use loads of different types on the same circuit.
2. Not suitable for use with any other load type.
3. *Neutral connection is required. It is recommended to connect neutral whenever possible to extend the load handling capability of the dimmer.
1-10V Dimmer
K34499
Rated Load
6AX
Maximum number of ballasts
10
Neutral connection is mandatory on 1-10V Dimmer. Suitable for use with dimmable fluorescent or LED lighting which is driven by
separate 0/1-10V control gear.
Suitable for use with 0/1-10V analogue dimmable ballast operating in accordance with IEC60929 annex E.
