Features
l
16 standard finishes
l
Many more customised
combinations of standard colours,
materials and finishes available
l
Bespoke colours, materials and
finishes available via the Design
Service
l
Touch sensitive electronic switch
with LED display
l
Standby light to assist location in
low light level applications
l
Soft start and off offers superior
user experience and prolongs
lamp life
l
Available as 1 and 2 gang
l
LED compatible (requires neutral)
l
High power switches up to 10A or
fluorescent load (10AX)
l
Intelligent overload protection
(not applicable to 10A switch)
l
2-way switching available
Electronic Switches
Description
Elements Electronic Switches offer intuitive touch sensitive silent switching (except
K34370) with LED displays, for a unique user experience.
Dimensions (mm)
1 gang
86
86
2 gang
28.15
7.35
86
86
28.15
7.35
Standards and approvals
All Elements electronic switches comply with
IEC 60669-2-1
TECHNICAL SPECIFICATION
ELECTRICAL
MAINS SUPPLY VOLTAGE
220-240V a.c. 50/60Hz
MAINS SUPPLY VOLTAGE RANGE
198 - 264V a.c.
MAINS SUPPLY FREQUENCY
50/60Hz ±3Hz
TERMINAL CAPACITY
All products
4 x 1mm²
4 x 1.5mm²
3 x 2.5mm²
2 x 4mm²
1 x 6mm²
PHYSICAL
OPERATING TEMPERATURE
-5°C to +40°C
IP RATING
IP4X
MAX. INSTALLATION ALTITUDE
2000 metres
To prevent damage to frontplates during installation
it is recommended that a screwdriver with a blade
width of 4mm is used.
MOUNTING BOX TYPE
The minimum depth required is 35mm.
When using 2.5mm² cables the minimum box depth
required is 40mm.
