493
Ceiling Roses and Pendants
Description
The range includes ShockGuard
™
SG type lampholders, pendant sets, batten
lampholders and ceiling roses.
Features
ShockGuard
™
l
Automatically shields the contacts
as soon as the lamp is removed
l
The contacts remain shielded
until a new lamp is slotted into
place
l
While there is no lamp in place
there is no danger of electrocution
Ceiling roses
l
Clear base and pre-cut aperture
for ease of installation
l
Clear markings
l
Terminal layout allows cables to
be cut to even length
l
Earth terminal point used for
easier cable access
l
Halo (K1163WHI) available
to give professional finish on
damaged ceilings (for use with
ceiling roses and pendant sets
only)
27
86
Ceiling Rose
Dimensions (mm)
Standards and approvals
Heat resistant lampholders comply with
BS EN 61184:1997 T2
All ShockGuard lampholders
comply with BS 7895:1997 and
BS EN 61184:1997 T2
Ceiling roses comply with BS 67:1987
Pendant sets are supplied with heat resisting
PVC insulated and sheathed flexible 0.75 two
core circular cable complying with
BS EN 50525 (H05V2V2-F)
TECHNICAL SPECIFICATION
ELECTRICAL
LAMPHOLDERS AND BATTEN LAMPHOLDERS
VOLTAGE RATING
250V a.c.
MAXIMUM RATING
150 watts
TERMINAL CAPACITY
Live, neutral & earth
3 x 1.0mm²
2 x 1.5mm²
CEILING ROSES & BASE OF PRE-WIRED BATTEN
LAMPHOLDERS
VOLTAGE RATING
250V a.c.
MAXIMUM RATING
6 amps
TERMINAL CAPACITY
Live, neutral & earth
4 x 1.0mm²
3 x 1.5mm²
1 x 2.5mm²
PHYSICAL
AMBIENT OPERATING TEMPERATURE
–5°C to +40°C
IP RATING
IP4X
MAX. INSTALLATION ALTITUDE
2000 metres
Pendant
Ceiling Accessories
Technical
WIRING DEVICES
WHITE
