Electronic Switches
LOAD RATING AND TYPE
Description
K34371 & K34372 (per gang)
K34370
GLS/ Tungsten Filament, Mains Tungsten Halogen
25 – 400W
25-2400W
Fluorescent tubes with ferro-magnetic ballast with power factor correction
*18-200VA
18-1800W
Fluorescent with electronic ballast
*18-400VA
18-540W
Low Energy PL-C and PL-S Fluorescent with Ferromagnetic ballast
*18-200VA
18-750W
Low Energy PL-C and PL-S Fluorescent with electronic ballast
*18-400VA
*18-750W
Compact Fluorescent (CFL)
*5-200W
*5-750W
ELV Tungsten Halogen with Ferro-magnetic transformer or Dimmable Electronic Transformer
50-400VA
(Refer to note 4)
50-1500VA
(Refer to note 4)
ELV Tungsten Halogen with Non-dimmable Electronic Transformer
*25-400VA
25 – 1500VA
Mains LED lamp for incandescent replacement
*4-150W
(Max. 15 lamps)
*4-500W
(Max. 15 lamps)
Ceiling Fan (Note: Not suitable for fan with remote controller function)
Not applicable
*1-2 Max. 250W
Ventilation Fan
*1-2 Max. 250W
Dimmable or non-dimmable LED Driver
*4-150W
(Max 10 LED drivers only)
*4-500W
(Max 10 LED drivers only)
Note:
1. Do not use loads of different types on the same circuit.
2. Not suitable for use with any other load type.
3. *Neutral connection is required. It is recommended to connect neutral whenever possible when dimming LED lamps, to extend the load handling capability
of the switch.
4. If neutral is connected to the switch then the minimum rating of the load can be reduced to 25VA.
