BETA Monitoring

Monitoring of Plants and Devices

5

TT5 2 EMERGENCY-STOP modules

14/11

Siemens ET B1 · 10/2008

14

Overview

EMERGENCY-STOP circuits are common safety measures in all lab-

oratory equipment and industrial plants. The EMERGENCY-STOP

modules used here must meet the most rigorous demands with

regard to functional reliability. Benchmark is the degree of self-

monitoring. The Machine Directive 98/37/EC, valid from 31.2.1994,

only specifies global safety standards. Details on how to implement

individual safety demands are defined in standards, e.g. by the

European Committee for Electrotechnical Standardization

(

CENELEC), which form the basis for international standards.

Benefits

The electrical isolation between electric circuit and control

meets the requirements of the standard

An LED for the operating and switching state provides

constant information on the operating state

The safety category 4 to EN 954-1 expands the application

options in many fields

Compliance with the regulations according to EC Machine

Directive 98/37/EC supports a high safety standard for those

working in the plants.

Technical specifications

5

TT5 200

Standards

IEC 60204-1; EN 60204-1 (VDE 0113-1)

Supply

Rated control voltage U

c

V AC

230

-

Operating range

× U

c

0.8 ... 1.1

Rated frequency f

n

Hz

50

Rated power dissipation P

v

Coil/drive

3.5

Contact per pole

VA

0.8

Control voltage

Terminal Y1

V AC/DC 24

Control current

Terminal Y1

DC mA

45

Recovery time

ms

500

Safety

Electrical isolation, creepage distances and clearances, actuator/contact

mm

3

Rated impulse withstand voltage U

imp

drive/contact

kV

> 4

Contacts

Contacts

NO contacts

AC-15

A

3

NC contacts

AC-15

A

2

NO contact/

NC contact

AC-1

A

5

Contact gap

mm

> 1

Electrical service life

AC-15, 2 A, 230 V AC

Switching

cycles

10

5

Reliable switching frequency

Switching

cycles/h

600

Vibration resistance

Amplitude

Acc. EN 60068-2-610 Up to 55 Hz mm

0.35

Terminals

Terminals

± screw (Pozidriv)

PZ 1

Conductor cross-sections of main current paths

-

Rigid

Max.

mm

2

2

× 2.5

-

Flexible, with end sleeve

Min.

mm

2

1

× 0.5

Permissible ambient temperature

°C

0 ...

+50

Resistance to climate

Acc. to EN 60068-1

0/55/04

© Siemens AG 2008
