BETA Measuring

Three-Phase Measuring Devices

7

KT1 39 LAN couplers

11/16

Siemens ET B1 · 10/2008

11

Overview

A LAN coupler supports the worldwide data recall of up to 10

multicounters and E-counters over a LAN link to the Internet.

The LAN coupler is used in conjunction with multicounters and

E-counters. Up to 10 devices can be linked with a LAN coupler.

In turn, the LAN coupler is connected to a LAN.

Data communication between the LAN coupler and the PC is

implemented using the TCP/IP protocol.

The supplied software can be used to call up the measurement

data over LAN coupler and transfer it to a PC. The measurement

data are constantly stored as a text file with a time and date

stamp. This allows users to create flexible designs to their own

specific solutions (e.g. data can be prepared using MS Excel).

Benefits

Integration of measuring devices in industrial or office

communication

Display of measurement data using the standard software

MS Excel

Use of existing local networks (LAN) for transmitting the

measurement data

TCP/IP data protocol enables a wide range of applications

Limit value signals with time information for all measured

values increases your plant's safety

Open software structure enables the implementation of customized

solutions for measured data indication and analysis

Worldwide communication of the measured values via LAN

One LAN coupler for 10 devices

Technical specifications

7

KT1 390

Standards

EN 61010-1

Supply

Rated control supply voltage U

c

V AC 230

Operating range

× U

c

0.8 ... 1.2

Rated frequency

Hz 50

Frequency ranges

Hz 45 ... 65

Rated power dissipation P

v

VA 5

Function

System start

Automatic when the control supply voltage is switched on

LAN coupler identification

Over the IP address

Device identification

By means of the device number

Transmission rate

Mbit/s 100

RS 485 interface for connection of measuring devices

Line

Version

STP (shielded twisted pair)

-

Minimum cross-section

mm

2

2

× 0.2/AWG 24

-

Maximum line capacity

pF/m < 50

-

Impedance

W 100

-

Maximum overall cable length

m 1800

-

Type of installation

Parallel connection

Safety acc. to EN 61010-1

Degree of pollution

2

Overvoltage category

II

Operating voltage category

V 600

Material

II

Clearances

mm 3

Creepage distances

-

In device

mm 4.3

-

On printed boards, not installed

mm 3

Test pulse voltage

1.2/50

s

kV 4

Test voltage

50

Hz, 1 min

kV 2.2

Terminals

± screw (Pozidriv)

1

Conductor cross-sections

-

Rigid, maximum

mm

2

1

× 2.5 or 2 × 1.5

-

Flexible, with end sleeve, minimum

mm

2

1

× 0.75

Ambient conditions

Ambient temperature

In operation

°C 0 ... +55

Relative humidity

In operation

% 80

Vibration

Sinus amplitude at 50 Hz mm ± 0.25

Degree of protection

Acc. to EN 60529

IP20, with connected conductors

Safety class

Acc. to EN 61010-1

II

Software requirements for PCs

Operating system

MS Windows 2000, Windows XP or Windows Vista

Software for communication

.

net Framework V1.1 (included in delivery)

Software for visualization

MS Excel, version 6 or higher

MS Excel macro for the display of data (included in delivery)

© Siemens AG 2008
