20/86 CI insulated enclosures
Radiated heat dissipation
2010 CA08103002Z-EN
Insulated distribution boards
Radiatedheatdissipation
CI...
Radiated heat dissipation of the insulated enclosures CI Part no. Dimensions
W x H x D
mm
Heat dissipation
W
Max. radiated heat dissipation of the CI insulated enclosures with separate
mounting, ambient air temperature +20 °C
CI23...-125
CI23...-150
187.5 x 250 x 150
187.5 x 250 x 175
33
36
CI43...-125
CI43...-150
CI43...-200
375 x 250 x 150
375 x 250 x 175
375 x 250 x 225
46
50
56
CI44...-125
CI44...-150
CI44...-200
CI44...-250
375 x 375 x 150
375 x 375 x 175
375 x 375 x 225
375 x 375 x 275
66
68
72
78
CI45...-200 375 x 500 x 225 89
CI48...-200
CI48...-250
375 x 750 x 225
375 x 750 x 275
138
164
Max. radiated heat dissipation of the CI insulated enclosures with use in
distribution boards to VDE 0660 Part 500
CI23-... 187.5 x 250 x 150
187.5 x 250 x 175
25
CI43-... 375 x 250 x 150
375 x 250 x 175
375 x 250 x 225
42
CI44-... 375 x 375 x 150
375 x 375 x 175
375 x 375 x 225
375 x 375 x 275
54
CI45-... 375 x 500 x 225 67
CI48-... 375 x 750 x 225
375 x 750 x 275
93
Notes When calculating the heat dissipation, the quadratic relationship
of current with the rated diversity factor α must be considered.
Pv = I2 x R
Pv’ = Pv x α2
If no data is available concerning the load
relationships of the individual circuits, the
rated diversity factor is selected conform to
VDE 0660 Part 500.
