Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

95 / 140

CI insulated enclosures
2010 CA08103002Z-EN
20/91
Openings of covers (D...STV) and flanges (FL...) for socket devices
European socket (Schuko) with grounding
provisions, 16 A, 5-pole
CEE, 16–125 A, 5-pole
d
b c
a
Part no. a
mm
b
mm
c
mm
d
mm
Cover 45 45 - 47
16 A
Flange 52 52 - 57
16 A
Part no. a
mm
b
mm
c
mm
d
mm
16 A 90 90 - 78
32 A 90 90 - 87
63 A 90 90 98 92
125 A 90 90 107 94
Terminals
K.../1 K.../4
a3
a2
a
a1
b1 b
c a5
Part no. a a1 a2 a3 b b1 c a5
K95/1/N 37 - 18.5 3 115 100 88 -
K95/4 130 100 15 3 115 100 88 31
K150/1 37 - 18.5 3 115 100 105 -
K150/4 130 100 15 3 115 100 105 31
K240/1 52 - 26 3 115 100 120 -
K240/4 190 150 20 3 115 100 120 46
K2X240/1 68 - 34 4 140 125 127 -
K2X240/4 254 200 27 4 140 125 127 62
D...-Ci...-RAL7032-STV, FL... STV..., K...
