20/84 CI insulated enclosures
Standards, measured values
2010 CA08103002Z-EN
Standards,measured valuesTechnical data
CI23… CI43… CI44… CI45… CI48…
General
Standards IEC/EN 60529
EN 50262
DIN 43656
DIN 43660
EN 60439-4 for individual CI...X enclosures and distribution boards assembled from CI enclosures up to
680 A. Can therefore be used for socket combinations and as components for site distribution boxes.
Climatic proofing Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature °C -40 - 80
Protection type IP65
Radiated heat dissipation
￫Page 20/86
Additional technical data for
UL/CSA approved devices
See UL report File No. E54120 ￫Chapter 23
Material properties
Material
Base Glass-fibre reinforced polycarbonate
Cover Non-reinforced polycarbonate
Surface treatment Corrosion-resistant
Color
Base RAL 7032, pebble grey
Cover Transparent, opaque or RAL 7032, pebble grey
Material properties
Electrical
Creepage resistance to IEC 60112
Base KB160, KC175
Cover KB100, KC200
Surface treatment to IEC 60093 Ω x 1013 > 1
Dielectric strength to IEC 60243-1 kV/mm 30
Thermal
Continuous thermal stability
Housing °C -40…120
Enclosure bolt °C 85
Sealing °C 80
Mechanical
IK code to EN 50102 Please enquire
Load bearing capacity kg 5 10 20 30 40
Chemical resistance
Resistant Acids < 10 %, mineral oil, alcohol, petrol, grease, saline solutions
Partially resistant Acids > 10 %
Non-resistant Alkalis, paraffin
Atmospheric
Saline spray IEC 60068-2-11
UV resistance Beneath
protective canopy
Water absorption to EN ISO 62 % 0.29
Flammability characteristics
Glow wire to VDE 0471 Part 2 °C 960
UL
Base UL94V1
Cover UL94V2
Halogen free Yes (lower section and cover)
