20/68 CI insulated enclosures
Accessories
2010 CA08103002Z-EN
Distribution board assembly
AccessoriesDistributionboardassembly
For use with For use with Part no.
Article no.
Price
See price
list
Std. pack
Cross plates for wall-mounting and floor-standing distribution boards
• For the connection of horizontal and vertical sections
• Including fixing material
– KVB-ID
002300
10 off
Assembly bracket
• For the connection of distribution boards and for transport units
• Including fixing material
Wall-mounting distribution board
top and bottom on WW... section
Wall-mounting distribution
board 2 off, floor-standing distri-
bution board 1 off
ARB-ID
002302
10 off
For enclosure assembly at
transport splits
– VS-TR-CI
002330
25 off
Lifting eye fixing
For securing TOR-GG eyebolts, M12 thread
Wall-mounting distribution
boards, floor-standing
distribution boards
Mounting in WS... vertical
profiles
– TOB-ID
093848
10 off
Lifting eyes kit
For lift eye fix, M12 thread
Wall-mounting distribution
boards, floor-standing
distribution boards
For fixing using TOB-ID to the
vertical sections
One set consists of 4 lifting eyes
– TOR-GG
048276
1 off
Fixing screw
For securing CI enclosures to the sections
For securing CI enclosures to
wall fixing brackets W...
and to profiles WS..., WW...
– LT284-M6X20-C
050325
100 off
Plinths
For mounting floor-standing distribution boards
Width 375 mm – SS5-ID0375
079611
1 off
Width 750 mm – SS5-ID0750
081984
1 off
Width 1125 mm – SS5-ID1125
084357
1 off
Width 1500 mm – SS5-ID1500
086730
1 off
Spray can for CI enclosure covers
For painting covers, color RAL 7032
Contents 400 ml/300 g
– SP-CI-RAL7032
005741
1 off
