Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

71 / 140

CI insulated enclosures
Accessories
2010 CA08103002Z-EN
Distribution board assembly 20/67
AccessoriesDistributionboardassembly
125 mm grid
spacing
Length For use with Part no.
Article no.
Price
See price list
Std. pack
Quantity mm
Cable anchoring rails
For T-slot cleats
2 x 125 250 KSV2-ID
060627
1 off
3 x 125 375 KSV3-ID
063000
1 off
4 x 125 500 KSV4-ID
065373
1 off
5 x 125 625 KSV5-ID
067746
1 off
6 x 125 750 KSV6-ID
070119
5 off
7 x 125 875 KSV7-ID
072492
1 off
8 x 125 1000 KSV8-ID
074865
1 off
9 x 125 1125 KSV9-ID
077238
5 off
For use with Part no.
Article no.
Price
See price list
Std. pack
Wall fixing bracket
• Including fixing material
• For wall-mounting distribution system
To secure the mounting frame at a distance of 12 mm from the wall WBW12-ID
001925
4 off
To secure the mounting frame at a distance of 25 mm from the wall
Floor-standing distribution board top mount
WBW25-ID
081983
10 off
To secure the mounting frame at a distance of 100 mm from the wall
Floor-standing distribution board top mount
WBW100-ID
084356
10 off
Corner plate for wall-mounting and floor-standing distribution boards
• For the connection of horizontal and vertical sections
• Including fixing material
EVB-ID
002299
10 off
16
n x 125
n = 2 – 9
KSV...-ID
KSV...-ID, WBW...-ID, EVB... HPL20067EN
