20/62 CI insulated enclosures
Distribution board enclosure with LV h.b.c. fuse switch-disconnector
2010 CA08103002Z-EN
Enclosures with components fitted
Enclosureswithcomponents fittedDistributionboardenclosurewith LVh.b.c. fuse switch-disconnector
Dimensions Fuse-link Rated
operational
current
Rated operational
voltage
Part no.
Article no.
Price
See price
list
Std. pack NH
component
Basic enclosure
Location Mounting system
Ie Ue Basic unit
W x H x D
mm Sizes A V AC
Other
Distribution board enclosures with LV h.b.c. fuse switch-disconnectors
• Sides closed, but with full area knockout, open top and bottom
• Transparent cover, cover fasteners can be sealed.
• Protection type IP65
• Fuse base fitted to steel mounting plate
• Mounting plate brought forward by 50 mm
• Terminal for connecting the fourth conductor (PEN)
• Stepped cable grommets ￫Page 20/29
NH00 100 660 GSTA00/I43/L
046384
1 off Left CI43-200
L3-CI43
GSTA00(-160)
HS 50-CI 100 690 GSTA00/I43/R
048757
Right
160 500 GSTA00-160/I43/L
034520
Left
160 500 GSTA00-160/I43/R
036893
Right
NH00 2 x 100 660 2GSTA00/I43
060622
Left
Right
CI43-200
L3-CI43
GSTA00(-160)
HS 50-CI 2 x 160 500 2GSTA00-160/I43
053504
Left
Right
NH00 100 660 GSTA00/I43-G
058249
Centre CI43-200
(rotated 90°)
L3-CI43
GSTA00(-160)
HS 50-CI
160 500 GSTA00-160/I43-G
055877
Centre
NH00 100 660 GSTA00/I44/L
051130
Left CI44-200
L3-CI43
GSTA00(-160)
HS 50-CI GSTA00/I44/M
053503
Centre
GSTA00/I44/R
055876
Right
160 500 GSTA00-160/I44/L
039266
Left
GSTA00-160/I44/M
041639
Centre
GSTA00-160/I44/R
044012
Right
NH00 2 x 100 660 2GSTA00/I44/L/R
062995
Left
Right
CI44-200
L3-CI43
GSTA00(-160)
HS 50-CI 2GSTA00/I44/L/M
065368
Left
Centre
2GSTA00/I44/M/R
067741
Centre
Right
2 x 160 500 2GSTA00-160/I44/L/R
046385
Left
Right
2GSTA00-160/I44/L/M
048758
Left
Centre
2GSTA00-160/I44/M/R
051131
Centre
Right
NH00 3 x 100 660 3GSTA00/I44
070114
Left
Centre
Right
CI44-200
L3-CI43
GSTA00(-160)
HS 50-CI
NH00 3 x 160 500 3GSTA00-160/I44
058250
Left
Centre
Right
Notes Fuse-links￫ Chapter 19: Circuit-breakers, fuses
00
/L
00
/R
250
35
50
375
80 80
375
100
107.5
250
00
/L
00
/M /R
00
/L
00
/M
00
/ R
375
375
22.5 22.5
100
107.5
GSTA00/I..., 2GSTA00/I..., 3GSTA00/I... HPL20062EN
