Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

65 / 140

CI insulated enclosures
Individual enclosures with LV h.b.c. fuse switch-disconnectors
2010 CA08103002Z-EN
Enclosures with components fitted 20/61
Individual enclosures with LV h.b.c. fuse switch-disconnector
225 250
200
500
690
NH1 K150/1 GSTA1/I45E
090150
1 off
225 400
315
500
690
NH2 K240/1 GSTA2/I45E
090151
1 off
Notes Fuse-links ￫ Chapter 19: Circuit-breakers, fuses
Dimensions Enclosure
depth
Rated
operational
current
Rated
operational
voltage
Fuse-link 5thterminalcan
be retrofitted
(neutral
conductor)
Part no.
Article no.
Price
See price
list
Std. pack
Ie Ue
mm mm A V AC Sizes
C
2 x M50/20
6 x M25/16
8 x M20
D
1 x M50/32
6 x M25/16
E
1 x M50/32
2 x M40/25
8 x M25/16
2 x M20
F
1 x M63/40
6 x M25/16
10 x M20
2 x M16
GSTA...I... HPL20061EN
