Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

9 / 543

60 mm system
System for flat busbars
2010 CA08103002Z-EN
SASY 16/5
Poles Rated opera-
tional current
For use with Part no.
Article no.
Price
See price
list
Std. pack
Ie
A
Busbar shrouds
• Silicone-free, chlorine-free
• Temperature-resistant up to 110 °C
• Self-extinguishing to UL 94
1000 mm long. – – 12 x 5
15 x 5
20 x 5
25 x 5
30 x 5
BBC-FL5
107173
10 off
– – 12 x 10
15 x 10
20 x 10
25 x 10
30 x 10
BBC-FL10
107174
10 off
Ratedoperational
current
Copper bars Length Copper
factor1) Material Part no.
Article no.
Price
See price
list
Std. pack
Ie
A mm mm
Flat busbars
160 12 x 5 1500 Copper, tinned CU12X5
034121
10 off
160 12 x 5 2250 Copper, tinned CU12X5-2250
005093
10 off
250 20 x 5 1500 Copper, tinned CU20X5
044092
10 off
250 20 x 5 2250 Copper, tinned CU20X5-2250
007466
10 off
460 20 x 10 1500 Copper, tinned CU20X10
041719
5 off
460 20 x 10 2250 Copper, tinned CU20X10-2250
009839
5 off
630 30 x 10 1500 Copper, blank CU30X10
051211
1 off
Notes 1) Calculation of material surcharge￫Chapter 23
Information relevant for export to North America
Product Standards UL508A; CSA-C22.2 No. 14;
IEC 60439-1; CE marking
UL File No. E300273
UL CCN NMTR, NMTR7
CSA File No. 236217
CSA Class No. 3211-37
NA Certification UL Listed, CSA certified
Conditions of Acceptability Refer to approbation report
Specially designed for NA ✓
Suitable for Feeder circuits
Max. Voltage Rating 600 V AC
BBS-..., CU...X HPL16005EN
