Ordering
Poles Rated opera-
tional current
For use with
Part no.
Article no.
Price
See price
list
Std. pack
I
e
A
Busbar supports
• Thermoplast, silicone-free, chlorine-free
• Halogen-free
• Self-extinguishing to UL 94
• RAL 7035
• Creepage resistance CTI 200
• Temperature-resistant up to 120 °C
IEC busbar supports
Can be fitted to all busbar sizes using
concertina system.
With internal screw holes.
3
630
12 x 5/10
15 x 5/10
20 x 5/10
25 x 5/10
30 x 5/10
BBS-3/FL
1) 2)
107066
10 off
4
630
BBS-4/FL
138381
10 off
UL busbar supports
Can be fitted to all busbar sizes using
concertina system.
With internal screw holes.
3
630
12 x 5/10
20 x 5/10
30 x 5/10
BBS-3/FL-NA
1) 2)3)
107067
10 off
PE/N busbar supports
Can be fitted to all busbar sizes using
concertina system.
Can be mounted individually.
2
630
12 x 5/10
15 x 5/10
20 x 5/10
25 x 5/10
30 x 5/10
BBS-2/FL
107069
10 off
1
630
BBS-1/FL
107161
10 off
Terminal shroud
For covering busbars.
–
–
BBS-3/FL
BBS-3/FL-NA
ES-BBS-3/FL
1) 2)3)
107068
10 off
UL bottom plate
• Silicone-free, chlorine-free
• Temperature-resistant up to 110 °C
• Self-extinguishing to UL 94
For use when air gap between busbars
and mounting plate is not sufficient.
1100 mm long.
–
–
BBS-3/FL
BBS-3/FL-NA
BBC-BT-NA
1) 2)
107172
2 off
Notes
1)
Current load￫Page 16/39
2)
Current load￫Page 16/39
Information relevant for export to North America
Product Standards
UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
CSA File No.
236217
CSA Class No.
3211-37
NA Certification
UL Listed, CSA certified
Conditions of Acceptability
Refer to approbation report
Specially designed for NA No
Yes
3)
Suitable for
Feeder circuits
Max. Voltage Rating
600 V AC
BBS-..., BBC-...
HPL16004EN
