SASY busbar system
Interval between busbar centers of 60 or 185 mm conforms to market requirements +++
Devices and adapter mount directly to rail without bore holes +++ System covering for optimal
protection against accidental contact +++ For application worldwide +++Type-tested in Eaton
control panel systems
D fuse switch-disconnector with flashing function - D02-LTS/63/3-R
Blink function signals tripped fuse link+++ Snap-action drive switches the load all-pole and
hand-autonomous+++ Available with/without integrated auxiliary contact ￫ Page 16/21
LV h.b.c. fuse switch-disconnectors - GST
Construction sizes 000, 00, 1, 2, 3 to 630 A +++ Easy, fast mounting to 60 mm systems +++
Comprehensive device accessories and fuse inserts LV h.b.c. ￫ Page 16/16
K connecting terminals
For cross sections from 16 to 4 x 185 mm² +++ Accepts round and ribbon cables +++
Conductor mounts easily from front ￫ Page 16/67
F3A flanges, ZSD-2K, DH-COMF comfort hinged handle
Insulating material or steel plate +++ Metric cable entry knockouts or cable grommets +++
Version with sponge rubber for direct cable inlet +++ Simple handling +++ Halogen-free +++
Hinge comfort grip for control panels +++ Fold instead of swing +++ Ergonomically formed
grip from cast zinc +++ For all market-typical profile semi-cylinders ￫ Pages 16/62, 16/81
Cable grommets and cable glands
For cable external diameters from 1 to 68 mm +++ Simple handling, high protection type +++
PG or metric ￫ Page 16/62
Accessories for control panel building
Optimally matched to busbar systems SASY, Chapter 16 +++ CI insulation material housing,
Chapter 20 +++ Steel plate wall housing CS, Chapter 21 +++ Installation distributor IVS,
Chapter 22 +++ Add-on board XVTL, Chapter 22 +++ Universal application in other control
panels
Prefabricated energy and control distribution
Our system partner switchgear systems operate prefabricated energy and control distributions
worldwide.
The innovative accessory for control panel construction is optimally matched to the Eaton
control and distribution systems. Whether cable management systems, connection and
interconnection technology or locking systems, Eaton accessories help you to realize your
applications easily and without wasting time.
SASY busbars system
Accessories for control panel building
