Busbar system
60 mm system
SASY 16/3
System covers 1
Partitioning of busbars or terminals
for increased personal safety.
Different versions, for individual
customization or ready to install in
defined dimensions.
For 3- and 4 pole systems.
￫Page 16/8
Cover for empty sections, modular 2
Spare section cover can be cut to
length.
Clipped on simply and quickly to the
support provided.
For 3- and 4 pole systems
￫Page 16/7
Cover for empty sections support 3
Simple push-fit, for all copper
busbars.
For 3- and 4 pole systems
￫Page 16/7
Terminal plates 4
Terminal modules protected against
direct contact, lockable.
For commonly available connection
cables and busbars.
For 3- and 4 pole systems
￫Page 16/7
Busbar end-to-end connectors 5
For interconnecting busbar systems.
For flat and profiled busbars.
￫Page 16/13
Universal conductor terminals 6
With integrated retaining spring.
Captive fixing screw.
Suitable for all copper, flat and
profiled busbars.
￫Page 16/12
Expansion terminals 7
For fitting to busbars without drilling
Cables can be inserted from the top
simply and quickly.
￫Page 16/10
Profiled busbars 11
Cross-sections 500, 720 and 1140 mm2.
Tin-plated surface for low contact
resistance
Tin-plated copper busbars cut time
needed to prepare contact points.
￫Page 16/11
Double T profile busbar supports 9
Cross-sections 500 mm2 (1250 A)
and 720 mm2 (1600 A)
Very high short-circuit rating for
greater system safety.
Fewer supports required.
Spacing between busbar centers
60 mm.
￫Page 16/6
Terminal shroud 10
For covering the copper busbar ends
for increased contact protection.
￫Page 16/6
Flat busbars 8
12 x 5 up to 30 x 10 mm, Cu.
￫Page 16/24
Busbar supports 12
For all commonly available flat
busbars.
Can be fitted to all busbar sizes using
concertina system.
For 3- and 4 pole systems
Versions for IEC and UL/CSA.
Spacing between busbar centers
60 mm.
￫Page 16/4
Terminal shroud 13
For covering the ends of flat copper
busbars
￫Page 16/4
Busbar adapters for PKZ and PKE 14
Mounting rails and connection
cables prepared for motor starter
combinations with PKZ, PKE or
DILM.
With combi-base suitable for 5 and
10 mm thick flat and profiled busbars.
Versions with connection cables for
spring-loaded terminals or without
electrical contact.
￫Page 7/22
Two-row double adapter for specific
applications, e.g. with fuses.
￫Page 16/21
Complete devices prefitted and
wired for DOL starters.
￫Page 8/26
Complete devices prefitted and
wired for reversing starters.
￫Page 8/28
Busbar adapters for NZM 15
Innovative terminal design for rear
connetion.
For all commonly available flat
busbars and for double T profile.
For 3- and 4 pole systems.
Conductors completely embedded
for maximum safety.
Easy mounting and terminal
connection
￫Page 16/14
LV h.b.c. fuse switch-
disconnectors 16
Switching devices NH000, NH00,
NH1, NH2 and NH3 up to 630 A.
￫Page 16/16
D fuse switch-disconnectors
without flashing function 17
Switch-disconnectors for D02 screw
fuses.
Clear contact position indication.
Screw caps available as
accessories.
￫Page 16/21
D fuse switch-disconnectors with
flashing function 17
Flashing function indicates blown
fuse link.
Switches the load on all poles and
without touching by hand.
With fuse plug, therefore no new
screw caps required.
Low heat dissipation.
With contact position indicator.
￫Page 16/21
D busbar mounting fuse devices 19
D02, DII and DIII with front and
bottom plate supplied.
￫Page 16/20
Fuse links 20
D01, D02, DII, DIII and C10.
￫Page 19/47
Fuse adapters 21
D01, D02 cartridge ring adaptes,
DII and DIII gage rings.
￫Page 19/47
Screw caps 22
D01, D02, DII and DIII.
￫Page 19/44
Disconnecting blades 23
Can be used instead of LV h.b.c. fuse
links.
Full contact blades.
LV h.b.c. fuse links 24
Compact construction size up to
100 A; NH00 fuses can also used in
NH000 devices.
Fuse links NH00, NH1, NH2 and NH3
up to 630 A.
High breaking capacity 120 kA.
￫Page 19/53
