60 mm system
Terminals and connectors
2010 CA08103002Z-EN
www.eaton.comSASY
16/9
SASYTerminalsandconnectors
Terminal
area
W × H
Width
Poles Rated
operating
current
I
e
Terminal capacity
For use with Cu
factor
Part no.
Article no.
Price
See
price list
Std. pack
⊙ Round conductor, solid
Round conductor,
flexible, with correctly
crimped ferrule
Round conductor,
stranded
Sectoral conductor,
solid
Sectoral conductor,,
stranded
Copper strip
▃Copper bar
mm mm
A
mm
Connection kit
• Silicone-free, chlorine-free
• Temperature-resistant up to 120°C
• Self-extinguishing to UL 94
• Creepage resistance CTI 200
Pole spacing adjustable.
Fixing direct over busbar terminal.
Includes shroud with adjustable width.
Loop-through is possible.
–
180 - 240 3
560
120 - 300 mm
2
MCM 300 - MCM 600.
20 x 5/10
25 x 5/10
30 x 5/10
Double T
profile
BBA-TP3/300
1)
107185
1 off
32 x 25 180 - 240
800
Up to
10 x 32 x 1
▃30 x 25
BBA-TP3/
CU-BAND
1)
107186
1 off
Adapted to Eaton NZM4.
Fixing direct over busbar terminal.
Loop-through is possible.
5 x 28
228
3
1600
Up to
(2 x) 10 x 50 x 1
Up to
▃ (2 x) 50 x 10
30 x 10
Double T
profile
CU-BAND
BBA-TP3/1000
2)4)
107207
1 off
Pole spacing adjustable.
Fixing direct over busbar terminal.
Includes shroud with adjustable width.
Loop-through is possible.
–
180 - 228 4
560
120 - 300 mm
2
MCM 300 - MCM 600.
20 x 5/10
25 x 5/10
30 x 5/10
Double T
profile
BBA-TP4/300
3)
138385
1 off
32 x 25 180 - 228
800
Up to
10 x 32 x 1
▃30 x 25
BBA-TP4/
Copper strip
3)
138386
1 off
Notes
1)
Each set contains 3 pole pieces.
2)
Equipment supplied: 1 x BBC-CS1, 3 x AKS1000.
3)
Each set contains 3 pole pieces.
4)
Calculation of material surcharge￫Chapter 23
BBA-TP...
