60 mm system
Terminals and connectors
2010 CA08103002Z-EN
SASY 16/11
Terminal
area
W × H
Width Rated
operating
current
Ie
Terminal capacity For use with Copper
factor1)
Part no.
Article no.
Price
See price
list
Std. pack
⊙ Round conductor, solid
Round conductor, flexible,
with correctly crimped
ferrule
 Round conductor,
stranded
 Sectoral conductor, solid
 Sectoral conductor,,
stranded
Copper strip
▃Copper bar
mm mm A mm
Profile terminals
Connects onto busbars without drilling
When
connecting
laminated
busbars in
parallel, fit a
spacer.
– 82 1600 750 mm2, terminal area
51 x 5 - 28
▃

Double T profile AKP750
138364
3 off
– 72 1600 800 mm2, terminal area
41 x 20 - 42
▃

AKP800
107198
3 off
– 94 1600 900 mm2, terminal area
64 x 5 - 28
▃

AKP900
138365
3 off
– 94 1600 1000 mm2, terminal area
51 x 20 - 42
▃

AKP1000
107199
3 off
– 94 2000 1200 mm2, terminal area
64 x 20-42
▃

AKP1200
138366
3 off
– 112 2500 1600 mm2, terminal area
81 x 20 - 42
▃

AKP1600
138367
3 off
– 132 3000 2000 mm2, terminal area
101 x 20 - 42
▃

AKP2000
138368
3 off
– 132 3200 3600 mm2, terminal area
101 x 23 - 45
▃

AKP3600
138369
3 off
Notes 1) Calculation of material surcharge￫Chapter 23
Information relevant for export to North America
Product Standards UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking
UL File No. E307559
UL CCN NMTR2, NMTR8
CSA File No. 236217
CSA Class No. 3211-37
NA Certification UL Recognized, CSA certified
Conditions of Acceptability Refer to approbation report
Suitable for Feeder circuits
Max. Voltage Rating 600 V AC
AKP... HPL16011EN
