16/16 60 mm system
Busbar fuse material
2010 CA08103002Z-EN
SASY
SASYBusbar fusematerial
SASYBusbar fusematerial
Connection Spacing
between
busbar centers
Rated
operational
current
Max. fuse link For use
with
Part no.
Article no.
Price
See
price list
Std.
pack
Ie 500 V 690 V Size
mm A A A
LV h.b.c. fuse switch-disconnectors
• Includes handguard top and bottom (except GST-160-40-60-AOU)
• Mounting without holes
• For surface mounting on busbars
3 pole
Box terminal
1.5 - 50 mm2
Bottom
60 100 100 – NH000 20 x 5/10
30 x 5/10
Double T
profile
LTS-100/C00/3-R
284690
1 off
Box terminal
1.5 - 70 mm2
Top or bottom
40
50
60
160 160 100 NH00 20 x 5/10
25 x 5/10
30 x 5/10
Double T
profile
GST00-160-40-60-AOU1)
224550
1 off
Screw M10
Top
60 250 250 200 NH1 20 x 5/10
25 x 5/10
30 x 5/10
Double T
profile
GST1-AO
107250
1 off
60 400 400 315 NH2 GST2-AO
107252
1 off
60 630 630 500 NH3 GST3-AO
107254
1 off
Screw M10
Bottom
60 250 250 200 NH1 20 x 5/10
25 x 5/10
30 x 5/10
Double T
profile
GST1-AU
107251
1 off
60 400 400 315 NH2 GST2-AU
107253
1 off
60 630 630 500 NH3 GST3-AU
107255
1 off
Size Rated operating
voltage
For use with Part no.
Article no.
Price
See price
list
Std. pack Notes
Ue
V
Handguard for switch-disconnectors
Provides additional protection for operator during actuation of fuse switch-disconnector
00 – GST00-160-… BS-SET-GST00
107955
1 off One set contains handguard
top and bottom.
Notes 1) Without handguard.
Order optional handguard BS-SET-GST00 ￫Page 16/16
LV h.b.c. fuse links ￫Page 19/53
LTS, GST... HPL16016EN
