24 / 543
16/20 60 mm system
Busbar fuse material
2010 CA08103002Z-EN
www.eaton.comSASY
Rated opera-
tional current
Rated operating
voltage
Size
Mounting
width
For use with
Part no.
Article no.
Price
See price
list
Std. pack
I
e
U
e
A
V AC
mm
D busbar mounting fuse devices
Basic units
• Includes contact protection shroud with front and bottom plate and designation label
• Supplied empty without screw cap
Cartridge ring
adapter
63
400
E18, D 02 27
12 x 5/10
20 x 5/10
25 x 5/10
30 x 5/10
Double T profile
D02-SO/63/3-R-27
1)
114315
10 off
Cartridge ring
adapter
E18, D 02 36
Z-D02/R/3-36
1)
100663
60 off
Cartridge ring
adapter
E18, D 02 54
Z-D02/R/3-54
1)
100664
40 off
Gage ring
25
500
E 27, D II
45
DII-SO/25/3-R
2)
107965
10 off
Gage screw
25
500
E 27, D II
45
DII-SO/25/3-R-PS
2)
110394
10 off
Gage ring
63
690
E 33, D III
54
DIII-SO/63/3-R
3)
107966
10 off
Gage screw
63
690
E 33, D III
54
DIII-SO/63/3-R-PS
3)
110395
10 off
Side cover
Can be fitted on right or left
Can be fitted to D…-SO/…/3-R(-PS)
–
–
–
–
–
DII-S0/…/3-R(-PS)
SBS-RS60
060541
10 off
Kit for fitting over busbar supports
Can be fitted to D02-SO/63/3-R-27
–
–
–
–
36
D02-S0/63/3-R-27
Z-D02-S-AB-SET
100662
10 off
Notes
1)
A complete and functional fuse element consists of the basic unit
•
Fuse link
￫Page 19/47
•
Fuse adapter
￫Page 19/47
•
Screw cap
￫Page 19/47
2)
A complete and functional fuse element consists of the basic unit
•
Fuse link
￫Page 19/43
•
Fuse adapter
￫Page 19/44
•
Screw cap
￫Page 19/44
3)
A complete and functional fuse element consists of the basic unit
•
Fuse link
￫Page 19/43
•
Fuse adapter
￫Page 19/44
•
Screw cap
￫Page 19/44
D02, Z-D02, DII, DIII
HPL16020EN
