Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

19 / 543

60 mm system
Busbar adapters for PKZ and PKE, accessories
2010 CA08103002Z-EN
SASY 16/15
SASYBusbaradapters forPKZandPKE,accessories
Rated operational
voltage
Conductor
cross-section
Adapter width For use with Support
rail
Part no.
Article no.
Price
See price
list
Std. pack
Ue
V AC mm Number
Busbar adapters for PKZ and PKE
Complete range ￫Chapter 7
For surface mounting to flat copper busbars with 60 mm between busbar centers, suitable for 5 mm and 10 mm
busbar thickness and also double T profile.
Mounted by latching onto de-energized busbar.
Connecting cables
– – – – BBA… – BBA-XLT-6-130
116902
30 off
– – – – BBA… – BBA-XLT-16-142
116903
30 off
Double adapters
Rated operational current 35 A
690 AWG 10
(6 mm²)
45 12x5/10
15x5/10
20x5/10
25x5/10
30x5/10
2 Z-SS-60-ADD/6-45
288790
1 off
690 AWG 10
(6 mm²)
54 12x5/10
15x5/10
20x5/10
25x5/10
30x5/10
2 Z-SS-60-ADD/6-54
288791
1 off
690 AWG 10
(6 mm²)
72 12x5/10
15x5/10
20x5/10
25x5/10
30x5/10
2 Z-SS-60-ADD/6-72
288792
1 off
690 AWG 10
(6 mm²)
81 12x5/10
15x5/10
20x5/10
25x5/10
30x5/10
2 Z-SS-60-ADD/6-81
288793
1 off
Information relevant for export to North America
Product Standards UL 508A; CSA-C22.2 No. 14; IEC60439-1;
CE marking
UL File No. On request
UL CCN On request
CSA File No. On request
CSA Class No. On request
NA Certification UL Recognized, CSA certified
BBA, Z-SS-60-ADD HPL16015EN
