www.eaton.comBusbar system
Compact System
SASY
16/23
Terminal plates
1
Simple connection by contacting the
conductor.
Full contact protection.
￫Page 16/25
Cover for empty sections, modular
2
Spare section cover can be cut to
length.
Clipped on simply and quickly to the
support provided.
Compact height.
For 3 pole systems.
￫Page 16/24
Empty sections cover support
3
Simple push-fit, for busbars 12 x 5/10.
For 3 pole systems.
￫Page 16/24
Busbar end-to-end connectors
4
For interconnecting busbar systems.
For flat busbars.
￫Page 16/26
Universal conductor Connection
terminals
5
With integrated retaining spring.
Captive fixing screw.
Suitable for all copper, flat and
profiled busbars.
￫Page 16/26
Expansion terminals
6
For fitting to busbars without drilling
Cables can be inserted from the top
simply and quickly.
￫Page 16/25
Flat busbars
7
12 x 5 and 12 x 10 mm, Cu.
￫Page 16/24
Busbar supports
8
Suitable for use with flat busbars
12 x 5/10.
Compact height.
For 3 pole systems.
Spacing between busbar centers
60 mm.
￫Page 16/24
Busbar adapters for PKZ and PKE
9
Mounting rails and connection
cables prepared for motor starter
combinations with PKZ, PKE or
DILM.
Compact height.
￫Page 7/23
Busbar adapters for NZM
10
Safe termination.
For 3 pole systems
Conductors completely embedded
for maximum safety.
Easy mounting and terminal
connection
￫Page 16/27
LV h.b.c. fuse switch-
disconnectors
11
Switching device NH000 up to 100 A.
Simple changing of termination
direction bottom/top.
Compact height.
￫Page 16/27
Disconnecting blades
12
Can be used instead of LV h.b.c. fuse
links.
Full contact blades.
LV h.b.c. fuse links
13
Compact construction size up to
100 A, NH00 fuses can also be used
in NH000 devices.
￫Page 19/53
D busbar mounting fuse devices
14
D02, compact height.
Box terminal for connecting cables
up to 25 mm
2
.
Integrated protection against direct
contact
￫Page 16/20
Fuse links
15
D.02
￫Page 19/47
Gage pieces
16
Gage rings D02.
￫Page 19/47
Screw cap
17
D.02
￫Page 19/47
